Hanwha Wisenet New-Q 16VH 4K PoE NVR, H.265, 128Mbps, 3TB HDD (2 SATA 12TB max) - QRN-1620S

Description

Description

The second generation of NEW-Q NVRs are here! This improved range has an enhanced Graphical User Interface (GUI) to make driving these new NVRs a breeze, increased PoE budget for higher performing cameras, dual track recording and dual monitoring.

In conjunction with the NEW Wisenet V2.0 mobile app, Hanwha now has a complete solution to offer the small to medium marketplace.

The QRN-1620S is a 16 channel NVR with the ability to record up to 8-megapixels and can produce a HDMI video output at a resolution of up to 3840 x 2160. The NVR can achieve plug and play via the 16 PoE ports, which are capable of up to 128Mbps. Supporting compression of H.265, this NVR can also sufficiently reduce storage space and costs by up to 50 percent, making it a cost-effective solution for a variety of security scenarios.

Features

  • Up to 16CH 8MP resolution
  • H.265, H.264, MJPEG codec
  • WiseStream support
  • 128Mbps network camera recording
  • Dual track recording
  • Plug & play by 16 PoE port
  • Max. 2 HDDs(Up to 12TB)
  • HDMI, VGA output
  • P2P service(QR code)
Datasheet
Tech Specs

Hanwha Wisenet NEW-Q 16VH 4K PoE NVR, H.265, 128Mbps, 3TB HDD (2 SATA 12TB max) - QRN-1620S

Display
Network camera Inputs Max. 16CH
Network camera Resolution 8MP ~ CIF
Network camera Protocols Wisenet, ONVIF
Decoding Local Display [Dual Display]
HDMI: 3840 x 2160, 1920x1080, 1280x720
VGA: 1920x1080, 1280x720
Decoding Resolution 8MP(60fps), 5MP(90fps), 3MP(120fps), 2MP(240fps),,720p(480fps), D1(480fps)
Performance
Record Compression H.265, H.264, MJPEG
Record Recording
Bandwidth		 Max. 128Mbps
Record Resolution 8MP ~ CIF
Record Mode Normal, Schedule(Continuous/Event), Event (Pre/Post), Dual track Recording
Record Event Trigger Alarm Input, Video Loss, Camera Event(Alarm, MD, Video Analytics, Defocus)
Record Event Action e-Mail, PTZ Preset, Alarm Out, Buzzer, Monitor Out
Search & Play Playback
Bandwidth		 Max. 32Mbps(16CH simultaneously)
Search & Play User Max. 4 Users (Local 1, Remote 3)
Search & Play Simultaneous
playback		 Max. 16CH(Network)
Max. 8CH(Local Monitor)
Search & Play Fisheye
Dewarping		 WEB / CMS / Mobile
Storage Supported HDD Up to 6TB
Storage HDD Slot SATA 2ea(Max. 12TB)
Backup File backup BU/Exe(GUI), JPG/AVI(Network)
Backup Function Multi channel(Upto 8CH) Play, Date-Time/Title display
Network
Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server,
Client), PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF
(Profile-S), SUNAPI(Server, Client)
DDNS Wisenet DDNS
Audio Input/Output 16CH(network)
Audio Compression G.711, G.726, AAC(16/48KHz)
Audio Communication 2-Way
Max Remote Users Search(3), Live Unicast(10), Multicast(20)
Security HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP)
Device Certificate(Hanwha Techwin Root CA)
Viewer Software SSM, Webviewer, Smart Viewer, Wisenet mobile
Support SDK/CGI(SUNAPI) for integration to 3'rd party VMS
Functions
Camera Setup Item IP address, Add profile edit, Bitrate, Compression, GOP, Quality, Camera MD
setup, Wisestream, Dynamic GOV/FPS, VA Setup
Camera video setup (Simple focus, Brightness/Contrast, Flip/Mirror, IRIS, WDR,
D&N, SSNR, Shutter, SSDR, DIS), Fisheye Dewarping Mode, Hallway View Setup,
Camera Webpage
Smart phone Support Model RTP, RTSP, HTTP, HTTPS, CGI(SUNAPI)
Smart phone Protocol
Support		 iOS, Android
Smart phone Control Live(Multi-Profile Support), Playback
Smart phone Max. Remote
Users		 Search(3), Live Unicast(10)
Redundancy ARB Support
Easy configuration Support
Interface
HDMI 1EA
VGA 1EA
Audio Out(1EA, RCA, Line)
Ethernet RJ-45(10/100/1000BASE-T) x 1
RJ-45(PoE+) x 16
Alarm In 4EA, Out 2EA
USB 2EA(Front 2)
Power inlet AC 1EA
System
System Control Mouse, IR remocon, Web
Language English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Swedish,
Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian, Greek,
Norwegian, Finnish, Korean, Chinese, Japanese, Thai, Vietnamese
Environmental
Operating Temperature 0°C to +40°C(32℉ to 104℉)
Operating Humidity 20% ~ 85% RH
Electrical
Power Input 100~240VAC±10%
Power Consumption Max. 158.2W(2HDDs, PoE on)
Max. 34.6W(2HDDs, PoE off)
PoE Budget Max. 130W
Mechanical
Color / Material Black / Metal
Dimension (WxHxD) W370.0 x H44.0 x D320 mm (14.57" x 1.73" x 12.6") (1U)
Weight 2.79Kg (6.15lb)

Read more

Hanwha Wisenet New-Q 16VH 4K PoE NVR, H.265, 128Mbps, 3TB HDD (2 SATA 12TB max) - QRN-1620S

Product form

SKU: QRN-1620S

Out of stock

$1,169.00 Incl. GST

    • Guaranteed secure & safe checkout.

      paypal
    • FREE Express Courier Shipping for all orders over $100
    • 30-Day Returns Policy
    • Back to Base Australian Warranty & Tech Support
    • Australian Stock, No Grey Import Products

    Product Datasheet
