Camera |
| Sensor |
5 MP 1/2.8" CMOS |
| Focal Length |
4mm |
| Maximum Aperture |
f/1.6 |
| Lens Field of View |
Horizontal: 80.1° |
| Vertical: 58° |
| Diagonal: 105.8° |
| IR Cut Filter |
Mechanical |
| Day/Night |
Yes |
| Minimum Illumination |
Color: 0.15 Lux |
| Shutter Speed |
1/12000 to 1/5 Seconds |
| Camera Angle Adjustment |
Horizontal: 0 to 350° |
| Vertical: 0 to 69° |
Video |
| Streaming Resolution |
2592 x 1944 at 30 fps |
| Supported Video Compression |
H.264, H.265, MJPEG |
| Multi-View Streaming |
Yes, 3 Streams |
Audio |
| Built-In Mic |
No |
Pan & Tilt |
| Pan/Tilt |
None |
Networking |
| Security |
Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, User Access Log |
| Supported Protocols |
ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, LLDP, NTP, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, TCP, UDP, UPnP |
System Integration |
| Application Programming Interface (API) |
ONVIF Profiles G, S & T, SUNAPI (HTTP API), Wisenet Open Platform |
| Analytics |
Motion Detection (4 Rectangular Zones), Defocus Detection, Tampering, People Counting |
| OS Compatibility |
Windows 7 |
| Windows 8.1 |
| Windows 10 |
| macOS 10.12 to 10.14 |
| *As of September, 2020: Check with manufacturer for the most up-to-date compatibility |
Sensors & Alarms |
| Event Trigger |
Yes |
| Event Action |
Recording, Notification, Alarm |
| Data Streaming |
Yes |
Hardware |
| Memory |
512 MB RAM / 256 MB Flash |
| Media/Memory Card Slot |
Single Slot: microSD/microSDHC/microSDXC [128 GB Maximum] |
| Internal Storage |
None |
| External Storage Options |
NAS |
Power |
| Power Source |
PoE 802.3af (15 W) |
| Power Consumption |
4 W |
Environmental |
| Operating Temperature |
14 to 104°F / -10 to 40°C |
| Storage Temperature |
-22 to 140°F / -30 to 60°C |
| Operating Humidity |
0 to 90% |
| IP Rating |
IP42 |
| Environmental Protection |
Advertised as Weather Resistant |
| *Manufacturer Testing: IP42 |
| IK Rating |
IK08 |
General |
| Inputs/Outputs |
1 x RJ45 |
| Material of Construction |
Plastic |
| Dimensions |
ø: 3.9 x H: 2.2" / ø: 99.0 x H: 56.0 mm |
| Weight |
0.4 lb / 165 g |
Packaging Info |
| Package Weight |
0.7 lb |
| Box Dimensions (LxWxH) |
6.1 x 5.6 x 4.7" |
