The AE-MD5043 Series Mobile Video Recorder is a professional in-vehicle DVR solution designed for reliable video and audio management. Running on a built-in Linux OS, it supports HDTVI, AHD, and CVBS camera inputs, and provides high-definition encoding/decoding, 4G data transmission, GPS positioning, and secure data storage.
Key Features
-
HD Camera Support: Access up to 4 HDTVI cameras with 1080p resolution.
-
Flexible Storage: Pluggable dummy HDD for up to 2TB storage, with SD card support up to 256GB.
-
Wireless Connectivity: Optional 4G and Wi-Fi modules for flexible data transmission.
-
GPS Positioning: Built-in GPS module records vehicle location in video streams.
-
Driving Data Collection: Captures signals such as braking, reversing, and turning.
-
Rugged Design: Aviation connectors ensure stable signals; fanless aluminum chassis enhances durability.
-
Power Protection: Wide 9–32V input, shutdown delay, super-capacitor protection, and data loss prevention.
-
User-Friendly Operation: Intuitive GUI with mouse, remote, touchscreen, or web browser control.
Downloads
Perfect For:
- Public transportation fleets
- School bus monitoring
- Taxi and ride-share security
- Logistics and trucking companies
- Fleet and learner-driver management
Installer Tips
-
Mounting: Ensure stable, vibration-resistant installation in the vehicle.
-
Power: Connect to 9–32 VDC supply, verify power-off protection is active.
-
Storage: Use HDD/SSD with vibration absorber for reliable operation.
-
Wireless: Install 4G/Wi-Fi antennas securely for optimal signal reception.
-
Testing: Verify GPS and alarm input/output functionality during setup.
Quick-Read Specs
| Specification |
Detail |
| Camera Inputs |
4-ch HDTVI/AHD/CVBS, max 1080p |
| Video Compression |
H.264 / H.265 |
| Storage |
1 × HDD/SSD up to 2TB, 1 × SD card up to 256GB |
| Wireless |
Optional 4G + Wi-Fi (2.4/5.8 GHz) |
| GPS |
Built-in GNSS (GPS + BeiDou) |
| Audio |
Two-way, EXT.DEV interface |
| Power Input |
+9 VDC to +32 VDC |
| Operating Temp |
-10 °C to +60 °C |
| Dimensions |
206 × 225.4 × 60.1 mm |
Device Weight
(Without Storage Media) |
1.7 kg (3.75 lb) |
Package Weight
(Without Storage Media) |
2.6kg（5.73 lb） |
Extra Info
Secure Data Protection
Equipped with a built-in super-capacitor, the DVR is safeguarded against sudden power interruptions, ensuring the device shuts down properly without risking hardware damage. Its advanced power-off protection mechanism guarantees that essential video recordings and system data remain intact, preventing loss of critical evidence during unexpected outages.
Rugged Vehicle Design
The system is engineered with a robust fanless aluminum die-cast chassis that enhances durability and longevity. Its fanless structure minimizes dust accumulation and mechanical wear, while the aluminum casing provides efficient heat dissipation. This design makes it highly reliable for harsh vehicle environments where vibration, temperature variations, and continuous operation are common.
Flexible Connectivity
With multiple interface options such as USB, RS-232, RS-422, and specialized aviation connectors, the DVR allows seamless integration with a wide range of peripherals and sensors. These connections expand system versatility, enabling integration with tracking systems, communication devices, and in-vehicle equipment for comprehensive fleet solutions.
Smart Management
Remote management is made simple and efficient through web browser access, allowing operators and administrators to monitor live feeds, configure settings, and review stored footage from virtually anywhere. This feature enhances fleet management efficiency by providing real-time oversight, reducing response times, and simplifying system maintenance.
Q&A
Q1: How many cameras can it support?
Up to 4 HDTVI/AHD/CVBS cameras with 1080p resolution.
Q2: Does it support GPS?
Yes, it includes built-in GPS + BeiDou GNSS positioning.
Q3: What storage options are available?
Supports 1 × HDD/SSD (up to 2TB) and 1 × SD card (up to 256GB).
Q4: Can it connect wirelessly?
Yes, with optional modules, it supports 4G data and Wi-Fi (2.4/5.8GHz).
Q5: Is it suitable for harsh environments?
It is built for standard environments but not recommended for highly corrosive areas like ports or chemical sites.
