| Maximum Video Resolution (Megapixels) |
8MP |
| Examples of Channels at a resolution with FPS |
320 Mbps |
| Video Compression |
H.264, H.265 |
| Video Output Resolution |
4K, HD-1080p, HD-720p, 1.3 MP, D1, VGA |
| Image Display |
1/4/6/8/9/10/13/14/16/17/19/22/25/32/36 |
| Search Method |
Continuous, Scheduling, Event Triggered ( PIR, IVS, Motion, Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Pedestrian Detection, Face Detection, Cross Counting) |
| Total Storage Potential (TB) |
112 |
| HDD Bays, Size |
Bays x 8, Up to 14TB per HDD |
| Software |
Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app |
| Protocols |
TCP, HTTP, HTTPS, DHCP, DDNS, NTP, SMTP, PPPOE, RTSP, UPnP, ONVIF, P2P, QR Code |
| Language |
English, French, Dutch, German, Italian, Polish, Portuguese, Spanish, Thai, Turkish, Hungarian, Simplified Chinese, Etc. |
| Audio Streaming |
Two Way |
| Power Over Ethernet Switch Ports |
32 up to 802.3at(30w) |
| Power Over Ethernet |
Yes |
| Power Supply |
Internal |
| Power Consumption |
17.5 W （Without HDD） |
| Connectors |
HDD: 3.5″ SATA HDD Slot x 8, USB3 Female x1, USB2 Female x 2, Gigabit Ethernet: RJ-45 Port x 1 and 32 x PoE+ ports, HDMI and VGA, e-Sata x1, Alarm ports 16 in and 4 out, RS485, Audio in and out, Power input x2, On off switch |
| Operating Environment |
5ºC to 45ºC (41ºF-113ºF) Humidity: 20%-80% RH |
| In The Box |
Printed quick installation guide, Mouse, Remote control, HDD screws, Power supply cable. |
| Warranty |
24 months parts |
| Dimensions |
440 x 460 x 89mm |
| Weight (kg) |
7.56kg |
