| Maximum Channels |
8 |
| Maximum Video Resolution |
12MP |
| Throughput |
128 Mbps |
| Video Compression |
H.264, H.264+, H.265, H.265+, MJPEG |
| Video Output Resolution |
4K, HD-1080p, HD-720p, 1.3MP, D1, VGA |
| Display Layout |
1 / 4 / 6 / 8 view |
| Intelligent Video (Camera Dependent) |
Perimeter Intrusion Detection, Face Recognition, Human & Vehicle Detection, Line Crossing, Stationary Object Detection, People Counting, Heat Map, Crowd Density, Queue Length, License Plate Recognition, Rare Sound Detection, Video Tampering |
| Search Methods |
Continuous, Scheduling, Event Triggered, IVS Filter, Snapshot, Tagging, Time-Lapse, Slice (Thumbnail Search), Timeline Search |
| Total Storage Potential |
32TB (2 × SATA HDD bays, up to 16TB per drive) |
| RAID |
Not Supported |
| Software |
Device Config Tool, Surveillance Client (CMS/VMS), Mobile App |
| Protocols |
TCP/IP, UDP, HTTP, HTTPS, DHCP, FTP, RTP, RTSP, DNS, DDNS, NTP, PPPoE, UPNP, SMTP, P2P (QR Code) |
| Language Options |
English, French, Dutch, German, Italian, Polish, Portuguese, Spanish, Thai, Turkish, Hungarian, Simplified Chinese, etc. |
| Audio Streaming |
Two-Way Audio |
| Non-PoE Ports |
1 |
| PoE Ports |
8 × PoE+ Ports (802.3at) |
| Power Supply |
DC 48V / 2A |
| Power Consumption |
5W (without HDD) |
| Connectors |
1 × 3.5" SATA Slot, 2 × USB2, 1 × RJ-45, 8 × PoE+, HDMI, VGA, Audio In/Out, Power Jack, On/Off Switch |
| Operating Environment |
5°C to 40°C (41°F–113°F), Humidity: 20%–80% RH |
| In The Box |
Printed Quick Installation Guide, Mouse, HDD Screws, Power Supply |
| Product Dimensions (H × W × L) |
50 × 380 × 340 mm |
| Weight (Gross) |
1.0 kg |
