| Camera Type |
PTZ |
| Image Sensor |
1/2.7” Progressive Scan CMOS |
| Maximum Video Resolution (Megapixels) |
5MP |
| Maximum Video Resolution |
2592×1944 |
| Lens |
4.3mm -142mm (H.FOV: 55 to 2.3°) |
| Lens Type |
Motorised Pan, Tilt and Zoom |
| Maximum Night IR Distance (M) |
150 |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| ONVIF depends on firmware version |
ONVIF (Profile S/G/T), HTTP API |
| IP Rating |
IP66 |
| Operating Environment |
(-)30ºC to 60ºC (-22ºF-149ºF) Humidity: ≤90% RH |
| Dimensions (H x W x L) mm |
206.4 x 206.4 x 351.8 mm |
| Weight (Net) |
3.7 kg |
| Accessories |
IV2488X |
| Power Supply |
Power over Ethernet IEEE 802.3at, DC12V |
| Power Consumption |
<26 W |
| Connectors |
RJ-45, DC Power Input, Audio In, Audio Out, Alarm in and out. |
| Outdoor Use |
Yes |
| Vandal Resistant |
Yes |
| Frames Per Second |
25 |
| Day/Night Mode |
auto |
| LED Types |
– |
| Image Enhancement |
Flip mode, Brightness, Contrast, Saturation, Sharpness, Hue, Mirror, Angle Flip, Back Light,
White Balance, Shutter, Time Exposure, Defog, 3D Noise Reduction |
| Edge Recording microSD/SDHC Card |
Micro SD/SDHC Card |
| Multiple Streams (encode format) |
4 Streams |
| Audio Streaming |
Yes – input connector for external mic |
| Protocols |
TCP/IP, UDP, HTTP, HTTPS, DHCP, FTP, RTP/RTSP, DNS, DDNS, NTP, PPPOE, UPNP, SMTP, SMTP, P2P (QR code) |
| Intelligent Video (IVS) |
Face Recognition, Human & Vehicle Detection, Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Crossing Counting, Heat Map |
| Cloud option (camera only) |
Dropbox |
| Software |
Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app (QR code) |
| Power Over Ethernet |
Yes |
| Ethernet |
Ethernet (10/100 Base-T) |
| In The Box |
Free Software available (ivsecurity.com.au/support/software), Printed quick user guide, installation template, mounting screws and plugs |
| Warranty |
3 Year Warranty |
