The IVSEC NC543ADX is a revolutionary panoramic IP camera delivering an expansive 180° field of view with 8MP Ultra HD resolution. Designed for high-performance surveillance, it ensures complete coverage with exceptional image detail. Its built-in AI analytics, vandal-resistant metal housing, and advanced deterrent LED options make it ideal for wide-area monitoring and professional installations.
Features:
-
8MP Ultra HD Resolution – 3840 × 2160 for crystal-clear panoramic coverage.
-
180° Panoramic Lens – 2.8mm wide-angle lens captures every corner with minimal blind spots.
-
Smart IR & Warm White LEDs – Choose between IR, Red & Blue, and Warm White light modes.
-
AI Detection – Supports motion, face, vehicle, pedestrian, region entrance/exiting, heat map, and license plate recognition.
-
Full Colour Night Vision – Clear colour images even in low-light environments.
-
Two-Way Audio – Built-in microphone and speaker for remote communication.
-
IP67 & IK10 Rated – Dustproof, weatherproof, and vandal-resistant for outdoor reliability.
-
Power over Ethernet (PoE) – Simplified single-cable installation.
-
Edge Recording – Supports microSD/SDHC cards for local video storage.
Downloads
100% Australian Owned | NDAA Compliant
Secure. Reliable. Australian.
IVSEC is an Australian brand offering high-quality video surveillance equipment at affordable prices. The IVSEC range of IP cameras is characterised by their ease of installation, intuitive settings, quality of finish, and Australian support.
Tech Specs
IVSEC Security Camera: 8MP, 2.8mm, 180° Panoramic, Two-Way Audio, IP67, IK10 - NC543ADX
| Camera Type |
Panoramic |
| Image Sensor |
1/2.7″ Progressive CMOS |
| Maximum Video Resolution (Megapixels) |
8 |
| Maximum Video Resolution |
3840 × 2160 |
| Frames Per Second (FPS) |
30 |
| Lens |
2.8mm (180°) |
| Lens Type |
Panoramic |
| Maximum Night IR Distance (M) |
30 |
| LED |
IR, Red & Blue, Warm White |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| ONVIF |
ONVIF (Profile S/G/T) – depends on firmware version |
| Accessories |
IV2422X, IV2433X, IV2444X, IV2455X, IV2457X, IV2477X |
| Outdoor Use |
Yes |
| IP Rating |
IP67 |
| Vandal Resistant |
Yes (IK10) |
| Day/Night Mode |
Day, Night, Auto, Schedule |
| Image Enhancement |
Rotate, Saturation, Brightness, Contrast, Sharpness, White Balance, BLC, 3D DNR, HLC |
| Intelligent Video (IVS) |
Motion Detection, Face Recognition, Pedestrian & Vehicle Detection, Line Crossing, Object Detection, Cross Counting, Heat Map, Crowd Density, Queue Length, License Plate Recognition, Intrusion, Region Entrance, Region Exiting |
| Edge Recording |
Micro SD/SDHC Card |
| Multiple Streams |
3 Streams |
| Software |
Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app (QR code) |
| Protocols |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP, PPPoE |
| Language |
English, French, Spanish, Portuguese, German, Italian, Greek, Danish, Finnish, Russian, Hebrew, Turkish, Bulgarian, Arabic, Korean, Japanese, Thai, Hindi, Romanian, Dutch, Polish |
| Cloud Option (Camera Only) |
Dropbox |
| Audio Streaming |
Yes (Microphone and Speaker Included) |
| Ethernet |
Ethernet (10/100/1000 Base-T) |
| Power Over Ethernet |
Yes |
| Power Supply |
Power over Ethernet IEEE 802.3at, DC12V |
| Power Consumption |
<14W |
| Connectors |
RJ-45, DC Power Input, Reset Button |
| Operating Environment |
-30ºC to 60ºC (-22ºF to 149ºF), Humidity ≤90% RH |
| In The Box |
Free Software from FTP, Printed quick user guide, Installation template, Mounting screws and plugs |
| Product Dimensions (H × W × L) mm |
127 × 136 × 136 |
| Packaging Dimensions (H × W × L) mm |
150 × 150 × 150 |
| Weight (Net) |
0.80 kg |
| Weight (Gross) |
0.50 kg |
| Warranty |
3 Year Warranty |
More Info
IVSEC Security Camera: 8MP, 2.8mm, 180° Panoramic, Two-Way Audio, IP67, IK10 - NC543ADX
Crystal Clear Clarity
High resolution ensures every detail is captured with precision, for the ultimate surveillance experience.
Capture the Moment
Incredible speed, providing you with smooth and seamless footage. Never miss a moment.
Cater to your surveillance needs
Device configuration tool enables seamless maintenance and allows searching the network for IVSEC devices.
Monitor & Update Remotely
View live camera footage, receive alerts on-the-go, schedule alarms and more with the iVSEC App.
Full Vivid Colour
Advanced features with vibrant colour and high-quality imaging at night.
Deter, Detect, and Defend
In built protection Siren, Flashing Lights, and Scheduling Assistant for Enhanced Security. Advanced Deterrent.
Value AI
Complete protection with accurate and targeted alerts to potential threats, reducing false alarms.
Professional AI
Now capable of processing advanced AI features, thanks to the inclusion of a specifically designed AI chipset.
Two-Way Audio
Allows for remote communication between the camera and a connected device.
Sensor & Schedule Light
Motion triggered smart night vision provides colour even in dark conditions.
Made to Withstand the Elements
With a metal casing, IP66 provides weatherproof monitoring and incredible durability.
Video Management Software
Aggregate NVR/IP cameras easily. Pool viewable camera channels and feeds at numerous locations.
