| AI Face Detection (by Cameras) |
8 channels |
| AI Face Detection (by Recorder) |
1 channel |
| AI Face Detection Features |
Whitelist, Blacklist, Stranger Mode |
| AI Face Detection Performance |
Up to 10 face databases with 200,000 face images |
| AI Face Recognition (by Cameras) |
8 channels |
| AI Face Recognition (by Recorder) |
1 channel (with Ultimate AI cameras) |
| AI Face Recognition Performance |
12 face images/s |
| AI Functions by Cameras |
Face detection, ANPR, People Counting, Heatmap, AI Tripwire/Intrusion and AI Human/Vehicle Detection |
| AI Functions by Recorder |
Face detection, face recognition, AI Tripwire/Intrusion and AI Human/Vehicle Detection |
| AI Motion Detection (by Cameras) |
8 channels |
| AI Motion Detection (by Recorder) |
4 channels |
| AI Search (Metadata) |
Support search target video by metadata |
| AI Tripwire/Intrusion (by Cameras) |
8 channels |
| AI Tripwire/Intrusion (by Recorder) |
2 channels, 10 IVS rules for each channel |
| Alarm Input / Output |
4 channel alarm inputs / 2 channel relay output |
| Auxiliary Inputs |
N/A |
| Backup Modes |
USB Device / Network |
| Decoding Capacity (AI Disabled) |
8CH@4MP/25fps |
| Decoding Capacity (AI Enabled) |
8CH@1080P/25fps |
| Dimensions |
375mm x 329mm x 53mm |
| Display Resolution |
Configurable from 3840 x 2160 to 1280 x 720 |
| Display Split |
1/4/8/9 |
| Ethernet |
1 RJ-45 port (10/100/1000Mbps) |
| Face |
Gender, age, glasses, beard, mask, expression |
| HDD Modes |
2 HDD (no RAID compatibility) |
| Human Body |
Tops style, tops colour, bottom style, bottom colour, hat , bag |
| Incoming Bandwidth (AI Disabled) |
256Mbps Mbps incoming (recording/outgoing) |
| Incoming Bandwidth (AI Enabled) |
180Mbps incoming (recording/outgoing) |
| Internal HDD |
1 SATA ports, up to 16TB, max. |
| Interoperability |
ONVIF 21.12, SDK, CGI conformant |
| Main Processor |
Industrial-grade processor |
| Max. User Access |
- |
| Network Functions |
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support VIP Vision IP camera, DVR, NVS and etc.) |
| Non-motor Vehicle |
Type, colour, people, number |
| Operating Environment |
-10 ~+55°C / 10~93%RH |
| Operating System |
Embedded LINUX |
| Optical Interface |
N/A |
| OSD |
- |
| Playback Sync |
1/4/8/9 |
| PoE |
Yes |
| Power Consumption |
NVR: 10W (without HDD) / PoE: Max 25.5W per port |
| Power over Ethernet |
8 ports (IEEE802.3at/af) |
| Power Supply |
100–240 VAC, 47-63 Hz |
| Rackmount Units |
1U |
| Rackmountable |
No |
| Record Interval |
- |
| Record Modes |
Manual / Schedule (Regular [Continuous], MD, Alarm) / Stop |
| Recording Resolution |
Configurable from 16.0MP (4920 x 3264) to CIF (352 x 288) |
| Remote View |
iOS (iPhone, iPad); Android devices, Windows Phone |
| Search Modes |
Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Trigger Events |
Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm |
| Two-way Talk |
- |
| USB Interface |
2 x USB ports (1 x Rear USB 2.0, 1 x Front USB 2.0) |
| Vehicle |
Vehicle colour, vehicle model, vehicle logo, plate colour, vehicle decorations, call, seatbelt |
| Video Compression |
H.265+ / H.265 / H.264 / H.264+ / MJPEG |
| Video Detection |
Motion Detection, Video Loss, Tampering & Scene Change |
| Video Input |
8 channel |
| Video Output |
1 HDMI / 1 VGA |
| Weight |
2.51kg (without HDD) |
