Description
Professional Series 5.0MP 2.8mm Fixed HDCVI Vandal Dome
The Securview Victory Series VSCVI2MPFBIR2-6 is a 2.0 megapixel, fixed lens, infrared bullet camera and is capable of providing 1080p High Definition footage over coaxial cable.
It uses the HDCVI video transmission standard which enables transmission distance up to 300m (1080p using 75-3 coax). Its compact size and IP66 rating makes it a perfect surveillance solution across a wide range of applications.
This camera is only compatible with digital video recorders in the Securview Victory Series.
Tech Specs
Alarm Interface |
N/A |
Angle of View |
98° |
Audio Input |
1 channel in |
Camera Type |
Dome |
Day/Night |
Auto (ICR) / Color / B&W |
Detect (25px/m) |
56m |
Dimensions |
Ø110 x 81mm |
Effective Pixels |
2592 (H) x 1944 (V) |
Electronic Shutter |
1/4s ~ 1/100,000s |
Focus |
Fixed / 0.8m Min. Focus Distance |
Frame Rate |
20fps (5.0MP) / 25fps (4.0MP and lower) |
Gain Control |
Auto |
Housing |
Metal & Polycarbonate |
Identify (250px/m) |
6m |
Image Sensor |
1/2.8” 5.0 Megapixel CMOS |
Infrared Range |
30m |
Ingress Protection |
IP67 |
Lens |
2.8mm F1.6 Fixed Lens |
Lens Type |
Fixed |
Lighting Compensation |
BLC / HLC / WDR (120dB) |
Max. Resolution |
2592 x 1944 |
Minimum Illumination |
0.005 Lux at F1.6 (Colour) / 0 Lux IR Active |
Mode Switching |
DIP Switches |
Modes Supported |
HDCVI, AHD, HDTVI & Composite |
Noise Reduction |
2D / 3D |
Observe (63px/m) |
22m |
Operating Environment |
-30° to 60°C / RH90% (max) |
OSD Menu |
Support |
Power Consumption |
<5.3W |
Power Input |
12VDC |
Recognise (125px/m) |
11m |
Resolution |
5.0MP (2592 x 1944) to CIF (352 x 288) |
Series |
Professional Series |
Signal Noise Ratio |
>65dB |
Synchronisation |
Internal |
Transmission Distance |
Rated for up to 700m via 75-3 coaxial cable (performed in ideal test conditions) |
Tri-Axis Mounting |
Yes |
Vandal Resistant |
IK10 |
Video Output |
1 x HDCVI / AHD / TVI / Composite video output (switchable via DIP switch) |
Weight |
0.33kg |
White Balance |
Auto / Manual |
