| Camera Type |
Dome |
| Series |
Professional AI Series |
| Model |
VSIPP-8DIRD-I3 |
| Image Sensor |
1/2.8” 8.0MP Progressive Scan CMOS |
| Effective Pixels |
3840 (H) × 2160 (V) |
| Lens / Iris |
2.8mm F1.4 Fixed Lens |
| Field of View |
Horizontal: 110° / Vertical: 58° |
| Min Illumination |
0.007 Lux/F1.4 (Color), 0.0007 Lux/F1.4 (B/W), 0 Lux (LED on) |
| Illuminator |
4x Warm LED + 3x IR LED, 30m range, Auto/Manual control |
| Video Resolution |
8.0MP (3840 × 2160) to CIF (352 × 288) |
| Frame Rate (Main) |
8.0MP (1 ~ 25fps) |
| Frame Rate (Sub / Third) |
1080p (1 ~ 25fps) |
| Video Compression |
H.265, H.264, Smart H.265+, Smart H.264+, AI H.265, AI H.264, MJPEG |
| Bit Rate |
3 ~ 16384Kbps |
| Bit Rate Control |
CBR / VBR |
| AI Functions |
Smart Motion Detection (SMD 4.0), Perimeter Protection, AcuPick AI Search |
| Day/Night |
Auto (ICR) / Color / B&W |
| Lighting Compensation |
BLC / HLC / True WDR (120dB) / AI SSA |
| White Balance |
Auto / Natural / Street Lamp / Outdoor / Manual / Regional Custom |
| Gain Control |
Auto / Manual |
| Noise Reduction |
3D DNR |
| Audio Interface |
Built-in Mic / 1 Input (RCA) / 1 Output (RCA) |
| Audio Compression |
G.711a, G.711Mu, PCM, G.726, G.723 |
| Alarm Interface |
1 Input (5mA 3–5VDC) / 1 Output (300mA 12VDC) |
| Edge Storage |
MicroSD Card (up to 512GB) / NAS / FTP / SFTP |
| Network Interface |
RJ-45 (10/100Base-T) |
| Protocols |
IPv4/IPv6, HTTP, TCP, UDP, RTSP, RTMP, SMTP, FTP, DHCP, DDNS, NTP, SNMP, P2P, ONVIF |
| Max. User Access |
20 Users (64MB Total Bandwidth) |
| Power Supply |
12VDC / PoE (802.3af) |
| Power Consumption |
Max <6.2W (12VDC) / 8.2W (PoE) |
| Operating Conditions |
-40°C ~ +60°C / ≤95% RH |
| Ingress Protection |
IP67 |
| Vandal Resistance |
IK10 |
| Housing |
Metal |
| Pan/Tilt/Rotation |
Pan: 0°–355° / Tilt: 0°–75° / Rotation: 0°–355° |
| Dimensions |
Ø89mm × 112mm |
| Net Weight |
0.53kg |
