The ENSA™ LED batten light series comprises customisable energy efficient lighting solutions that deliver control over your lighting, without the need for a complex management system. Models are available as standard sensor batten lights or as an emergency sensor batten light fitted with an emergency backup battery for over 5 hours light uptime.
Intelligent emergency battens feature motion detection, on-time delay and standby time delay functions to tailor your light use for efficiency & practicality. Each model features 2-stage dimming and can be configured to stay at 100% brightness, to dim and then turn off, or to dim and stay dimmed.
• Tailor your light use to further compound energy savings.
• Adjustable light-use controls such as on-time delay.
• Sensor can detect motion through glass and thin walls.
• Built tough housing: IP65 dust and weather resistant.
• Emergency lighting models are AS2293.3 approved.
• Easy access TEST button for emergency light testing.
• NSW ESS Accepted
Datasheets
Tech Specs
| Ambient Light Sensor | N/A |
| Battery Backup | N/A |
| Beam Angle | 123° |
| Certifications | IPART |
| Colour Rendering Index | > 80 |
| Colour Temperature | 6000K |
| Dimensions | 1260 x 108 x 85mm |
| Dimmable | Yes |
| Dimmed Brightness | 20% / 40% / 60% / 100% (default: 20%) |
| Dimming Information | Turn off / Time delay / Always on |
| Dimming Timeout | 0s / 90s / 180s / ?s (default: ?s) |
| Emergency Power Output | N/A |
| Equivalent Wattage | N/A |
| Ingress Protection | IP65 |
| Input Voltage | 220 ~ 240VAC (50 ~ 60Hz) |
| Installation Materials | Mounting clips, mounting screws & wall plugs, cable |
| Light Decay | L70 at 54,000 hours |
| Light Output | 3900lm |
| Luminous Efficacy | 108lm/W |
| Motion Activated | Yes |
| Motion Detection | 360° 5.8GHz Microwave / 8m max. radius / 50% ~ 100% adjustable (default: 100%) |
| NSW ESS Accepted | Yes |
| On-Time Delay | 5s / 30s / 90s / 180s (default: 90s) |
| Operating Environment | -20° ~ 40°C |
| Plug / Socket / Base | Internal terminal block |
| Power Consumption | 36W |
| Power Factor | >0.9 |
| Rated Lifespan | 54,000 hours |
| Reflector / Diffuser | Frosted diffuser |
| Standby Light Modes | N/A |
