| Alarm Interface |
2 Inputs / 1 Output |
| Audio Interface |
1 Input, 1 Output / Compression: G.711a, G.711mu, G.726, AAC |
| Auto Tracking |
N/A |
| Bit Rate |
H.265/H.264: 448 ~ 8192Kbps |
| Bit Rate Control |
Constant bit rate (CBR) / Variable bit rate (VBR) |
| Camera Type |
PTZ Dome |
| Day/Night |
Auto (ICR) / Color / B&W |
| Detect (25px/m) |
883m |
| Dimensions |
Ø170mm x 155mm |
| Edge Storage |
MicroSD Card (up to 256GB) / NAS / Local PC |
| Effective Pixels |
1920 (H) x 1080 (V) |
| ePoE |
No |
| Ethernet |
RJ-45 (10Base-T/100Base-TX) |
| Field of View |
Horizontal: 59° ~ 5° (12x Optical Zoom) |
| Focus |
Auto/Manual / 1m Min. Focus Distance |
| Frame Rate (Main) |
1080p (1 ~ 25fps) |
| Frame Rate (Sub) |
D1 (1 ~ 25fps) |
| Frame Rate (Third) |
720p (1 ~ 25fps) |
| Gain Control |
Auto / Manual |
| Housing |
Metal |
| Identify (250px/m) |
88m |
| Image Sensor |
1/2.8" 2.0MP Starvis™ CMOS |
| Infrared |
No |
| Infrared System |
N/A |
| Ingress Protection |
IP66 |
| Intelligent Functions |
Tripwire, Intrusion, Abandoned/Missing Object, Face Detection, Motion Detection, Region of Interest, Privacy Masking (24 zones), Defog |
| Interoperability |
ONVIF / PSIA / CGI |
| IVS |
Yes |
| Lens / Iris |
5.3 ~ 64mm F1.6 ~ F4.4 Motorised Lens |
| Lens Type |
Motorised Varifocal |
| Lighting Compensation |
BLC / HLC / WDR (120dB) |
| Max. Resolution |
2.0 Megapixel |
| Max. User Access |
10 Users / 20 Users |
| Min Illumination |
0.005 Lux/F1.6 (Color), 0.0005 Lux/F1.6 (B/W) |
| Modes / Presets |
Up to 300 presets / 5 Pattern, 8 Tour, Auto Pan, Auto Scan |
| Net Weight |
1.8kg |
| Noise Reduction |
Ultra 2D/3D DNR |
| Observe (63px/m) |
353m |
| Operating Conditions |
-30° ~ +60° C / Less than 90% RH |
| Pan / Tilt Range |
Pan: 0° ~ 360° (endless) / Tilt: -2° ~ 90° / Auto-flip 180° |
| Pan/Tilt/Rotation |
Pan: 0° ~360 ° ; Tilt: -2° ~ 90° ; Rotation: 0° ~ 360° |
| Picture Control |
Flip 180° |
| Power Consumption |
<12W |
| Power Supply |
24VAC/1.5A / PoE+ (802.3at) |
| Protocol |
IPv4/IPv6; HTTP; HTTPS; SSL; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMP; RTSP; RTP; SMTP; NTP; DHCP; DNS; PPPOE; DDNS; FTP; IP Filter; QoS; Bonjour; 802.1x |
| PTZ Speed |
Preset: Pan: 300°/s; Tilt: 200°/s Manual: Pan: 300°/s; Tilt: 120°/s |
| RAM / ROM |
1024MB / 128MB |
| Recognise (125px/m) |
177m |
| Resolution |
1080p (1920 x 1080) to CIF(352 x 288) |
| RS485 |
N/A |
| RTMP Support |
No |
| S/N Ratio |
> 55dB |
| Series |
Professional Series |
| Smart Scene Adaptive (SSA) |
No |
| Start-up Action |
Auto-restore to previous PTZ/lens status |
| Streaming Method |
Unicast / Multicast |
| Tri-Axis Mounting |
No |
| Ultra Low Light Colour |
Yes |
| Vandal Resistance |
IK10 |
| Video Compression |
H.265 / H.264 |
| Video Interface |
N/A |
| Weather Resistance |
Yes |
| White Balance |
Auto / ATW / Indoor / Outdoor / Manual |
