Uniview 4 Channel Security System: 4K NVR, 2 x 5MP LightHunter Turret Cameras, 2TB HDD

SKU 4CH2STARLIGHT-2TB
by Uniview
2 reviews
Save up to $184.00 Save $39.00
Original price $703.00
Original price $703.00 - Original price $1,438.00
Original price $703.00
Current price $664.00
$664.00 - $1,438.00
Current price $664.00
Upgrade NVR: 4 Channels (NVR301-04-P4)
Upgrade Hard Drive: 2TB Hard Drive
Description
DescriptionThe Uniview 4-channel 2-camera kit is a great home security system starter that can be upgraded later when you're ready to add more cameras. IPC3615SB-ADF28(40)KM-I0 is a 5-megapixel LightHunter IP camera. It comes with an exceptional high-clarity resolution, infrared night vision, and LightHunter illumination technology that ensures ultra-high image quality in a low illumination environment.

Choose between a 4 channel Network Video Recorder (NVR301-04-P4), 8 channel (NVR301-08X-P8) or 16 channel NVR (NVR302-16S-P16), all capable of recording in 8 megapixel (4K) resolution. Enjoy plug and play functionality and long range PoE+, capable of connecting, powering and streaming cameras from 250-300 metres away. All NVR's utilise Ultra265 video compression, a Uniview innovation that compresses video, maximising efficiency of bandwidth and storage capacity.

Viewing your cameras remotely is possible through the EZ View app for smart devices (iOS, Android), by internet explorer web browser or free video management software for mac or PC (EZStation), allowing set up and control of various functions of your system as well as Live viewing.

Designed by market leaders in innovation, Uniview’s quality cameras are popular with professional CCTV installers worldwide, often being used for large commercial projects.

Warranty

3 years back-to-base manufacturer warranty

FEATURES

  • 2 x 5 megapixel (5MP) LightHunter Illumination Turret Cameras, with Optional 2.8mm (Standard) or 4mm fixed lens
  • OPTIONAL 4 Channel, 8 channel or 16 channel NVR. All support 8MP (4K) Recording with 4 - 16 independent POE ports (Plug and Play)
  • NVR Options are NVR301-04-P4, NVR301-08X-P8 or NVR302-16S-P16
  • 2 Terabyte pre-installed hard drive (upgradable to 10TB)
  • Access your Live video feed on your smart device with EZView app. Supports android and ios
  • Smart Functions include Motion Detection, Intrusion Detection, Cross-Line Detection and Audio Detection.
  • Supports Audio Recording and comes with Built-In Mic.
  • Third-party IP cameras supported with ONVIF conformance
  • LightHunter Technology ensures ultra-high image quality in a low illumination environment.
  • Accurate retrieval, instant playback
  • Video Compression Ultra H.265, H.265, H.264, MJPEG - Triple Streams
  • 120 dB WDR (Wide Dynamic Range), 3D DNR
  • Smart IR night vision, up to 30m IR distance
  • 4 KV surge protection, IP67 weather protection
  • WARRANTY: 3 years back-to-base manufacturer warranty

More Info
More Info

Easy Set-up

  • POE+ Power Over Ethernet - No need for power sockets for each camera. Both power and video transmission are provided through one single ethernet cable from NVR to camera, making installation fast and easy. This kit has an NVR that supports POE+ Typically its possible to run 100 metres of POE cable from NVR to camera. Camera’s and NVR’s in the building kit can be connected with up to 250 metres of Cat5E or Cat6 cable without the need for repeaters or extenders.

  • DC12V Output - No need for extra cable to run a microphone, light or siren. Camera's with the Building Pack have DC12V output built into the camera so no need for an additional power supply.

Optics

  • Day/night functionality - Designed to operate just as good in total darkness as well as light.
  • Smart IR - Works by auto balancing infrared over-exposure which can be produced when the object gets too close to the camera at night.

  • IR Cut Filter - Automatically makes the transition from night to day, or from infrared night mode to daylight recording.

  • Up to 120 dB Optical WDR(Wide Dynamic Range) - Enables balanced lighting across the entire video image in unstable lighting conditions, such as when the background is bright and the foreground is dark.
  • 2D/3D DNR (Digital Noise Reduction) - Digital Noise Reduction (DNR) is a method by which the camera's imager digitally removes noise from the image. 3D DNR is an advancement of this technology which enables noise to be filtered even more effectively from the image, even in low light conditions.
  • Digital Defog - Developed with laser infrared, it actively penetrates fog whether natural or man-made to reproduce details perfectly.

Audio

  • Supports Audio recording - Camera has built-in mic and the NVR can support recording audio.

Compression

  • Ultra 265, H.265, H.264, MJPEG - U-code is an innovation developed by Uniview as an enhanced encoding technology to reduce the bitrate of H.265 even further, calling it ultra H.265. It does deep compression separating moving targets and static backgrounds. Ultra H.265 reduces bandwidth and storage an incredible 50%-95% over standard H.264/H.265.
  • Embedded smart algorithm
  • Triple streams - You have the ability to set multiple, independent video streams simultaneously from the IP camera. Each stream can be set at different frame rates, resolution and quality level, ideal if you require remote viewing over a limited-bandwidth connection, but want to retain the highest resolution for recording and local viewing. Triple streams give much more flexibility to users.
  • ROI (Region of Interest) - ROI is an intelligent video innovation designed to maximise image quality, network bandwidth and storage capacity. The system will monitor a specific, allocated region in full high definition, such as number plates or faces, while lowering resolution in less important parts of the image, for example the sky.
  • 9:16 corridor mode - For narrow, vertical scenarios such as hallways, that reduces wasted video compression, transmission and storage. The 9:16 aspect ratio rotates the image by 90 degrees and reduce the proportion of blank walls in the picture allowing the camera to focus on the most valuable areas—the doorway.
  • Customised OSD (On Screen Display) - The text displayed on the screen with video images and may include time and other customised content.

Network

  • ONVIF Conformance - Onvif (Open Network Video Interface Forum) refers to the camera’s compliance to a global open standard for the interface of IP cameras and how they communicate with each other.

Structure

  • Wide temperature range: -35°C to 60°C (-31°F to 140°F)
  • Wide voltage range - Uniview products are designed to handle fluctuations in voltage of +-25% Typically its only +-10% with competitor products.
  • IP67 - Cameras are sealed against extreme weather, water and dust.

      2TB SKYHAWK SURVEILLANCE HARD DRIVE - ST2000VX008

      • Built to record 90% of the time — supports up to 64 cameras
      • Up to 10 TB or 2,000+1 hours of HD video
      • 180 TB/year workload rating, 3× the workload of a desktop drive and backed by a 3-year limited warranty
      • NVR ready drives deliver robust drive design for multi-drive environments
      Tech Specs
      Tech Specs

      UNIVIEW 4 CHANNEL COMPACT 8MP (4K) NVR - NVR301-04-P4

      Model NVR301-04-P4
      Video/Audio Input
      IP Video Input 4-ch
      Two-way Audio Input 1-ch, RCA
      Network
      Incoming Bandwidth 40Mbps
      Outgoing Bandwidth 64Mbps
      Remote Users 128
      Protocols P2P, UPnP, NTP, DHCP, PPPoE
      Video/Audio Output
      HDMI/VGA
      Output
      HDMI:
      4K (3840 x 2160) /30Hz, 1920 x 1080p /60Hz, 1920 x 1080p /50Hz, 1600 x 1200 /60Hz, 1280 x 1024 /60Hz, 1280 x 720
      /60Hz, 1024 x 768 /60Hz VGA:
      1920 x 1080p /60Hz, 1920 x 1080p /50Hz, 1600 x 1200 /60Hz, 1280 x 1024 /60Hz, 1280 x 720 /60Hz, 1024 x 768 /60Hz
      Recording Resolution 8MP/6MP/5MP/ 4MP/3MP/1080p /960p/720p /D1/2CIF/CIF
      Audio Output 1-ch, RCA
      Synchronous Playback 4-ch
      Corridor Mode Screen 1/3
      Decoding
      Decoding format Ultra 265, H.265, H.264
      Live view
      /Playback
      8MP/6MP/ 5MP/4MP/ 3MP/1080p /960p/720p /D1/2CIF/CIF
      Capability 1 x 4K@30, 2 x 4MP @30, 4 x 1080p @30, 8 x 720p @30, 16 x D1
      Hard Disk
      SATA 1 SATA interface
      Capacity up to 8TB for each disk
      Smart
      VCA Detection Face detection, Intrusion detection, Cross line detection, Audio detection, Defocus detection, Scene change detection, Auto tracking
      VCA Search Face search, Behavior search
      Statistical Analysis People counting
      External Interface
      Network Interface 1 RJ-45 10M/100M self-adaptive Ethernet Interface
      USB Interface Rear panel?2 x USB2.0, Front panel?1 x USB2.0
      Alarm In 4-ch
      Alarm Out 1-ch
      PoE
      Interface 4 independent 100 Mbps PoEnetwork interfaces
      Max Power Max 30W for single port
      Max 54W in total ( 13.5W for each )
      Supported Standard IEEE 802.3at, IEEE 802.3af
      General
      Power Supply 48V DC
      Power Consumption: ? 5 W ( without HDD )
      Working Environment -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ? 90% RH (non-condensing)
      Dimensions(W× D×H) 260mm × 240mm × 44mm (10.2" ×9.4" ×1.7")
      Weight
      ( without HDD )
      ? 1.12 Kg ( 2.47 lb )



      OPTIONAL: UNIVIEW NVR301-08X-P8 | 8 CHANNEL 8MP (4K) NVR

      Model NVR301-08X-P8
      Video/Audio Input
      IP Video Input 8-ch
      Two-way Audio Input 1-ch, RCA
      Network
      Incoming Bandwidth 80Mbps
      Outgoing Bandwidth 64Mbps
      Remote Users 128
      Protocols P2P, UPnP, NTP, DHCP, PPPoE
      Video/Audio Output
      HDMI/VGA Output HDMI:
      3840x2160/30Hz,1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
      VGA:
      1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
      Recording Resolution 4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
      Audio Output 1-ch, RCA
      Synchronous Playback 8-ch
      Corridor Mode Screen 3/4/5/7/9
      Decoding
      Decoding format Ultra 265/H.265/H.264
      Liveview/Playback 4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
      Capability 2 x 4k@30, 3 x 5MP@30, 4 x 4MP@30, 5 x 3MP@30,8 x 1080p@30
      Hard Disk
      SATA 1 SATA interface
      Capacity up to 10TB for each disk
      External Interface
      Network Interface 1 RJ45 10M/100M self-adaptive Ethernet Interface
      USB Interface Rear panel: 1 x USB2.0,1 x USB3.0
      PoE
      Interface 8 independent 100 Mbps PoE network interfaces
      Max Power Max 30W for single port
      Max 108W in total (13.5W for each)
      Supported Standard IEEE 802.3at, IEEE 802.3af
      General
      Power Supply 52V DC
      Power Consumption: ?8 W (without HDD)
      Working Environment -10°C ~ + 55°C (+14°F ~ +131°F), Humidity ? 90% RH (non-condensing)
      Dimensions (W×D×H) 260mm × 240mm × 47mm (10.2"×9.4"×1.9 ")
      Weight (without HDD) 1kg (2.20 lb)


      OPTIONAL: Uniview 16 Channel 8MP (4K) Network Video Recorder -
      NVR302-16S-P16

      NVR302-16S-P16
      Video/Audio Input
      IP Video Input 16-ch
      Two-way Audio Input 1-ch, RCA
      Network
      Incoming Bandwidth 160Mbps
      Outgoing Bandwidth 96Mbps
      Remote Users 128
      Protocols P2P, UPnP, NTP, DHCP, PPPoE
      Video/Audio Output
      HDMI/VGA
      Output
      VGA: 1024X768@60, 1280X720@60, 1280X1024@60, 1920X1080@50,1920X1080@60 HDMI:
      4k(3840x2160@30), 4k(3840x2160@60), 1024X768@60, 1280X720@60, 1280X1024@60, 1920X1080@50,
      1920X1080@60
      Recording Resolution 8MP/6MP/5MP/4MP /3MP/1080p/960p/ 720p/D1/2CIF/CIF
      Audio Output 1-ch, RCA
      Synchronous Playback 16-ch
      Corridor Mode Screen 3/4/5/7/9/10/12/16
      Decoding
      Decoding format Ultra265/H.265/H.264
      Live view/ Playback 8MP/6MP/5MP/4MP/ 3MP/1080p/960p/ 720p/D1/2CIF/CIF
      Capability 1 x 4K@30, 2 x 4MP@30, 3 x 3MP@25, 4 x 1080P@30, 8 x 720P@30,16 x D1
      Hard Disk
      SATA 2 SATA interfaces
      Capacity up to 10TB for each disk
      Smart
      VCA Detection Face detection, Intrusion detection, Cross line detection, Audio detection, Defocus detection, Scene change detection, Auto tracking
      VCA Search Face search, Behavior search
      Statistical Analysis People counting
      External Interface
      Network Interface 1 RJ-45 10M/100M/1000M self-adaptive Ethernet Interface
      USB Interface Front panel: 1 x USB2.0, Rear panel: 1 x USB2.0
      Alarm In 4-ch
      Alarm Out 1-ch
      PoE
      Interface 16 independent 100Mbps PoE network interfaces
      Max Power Max 30W for single port
      Max 240W in total ( 15W for each )
      Supported Standard IEEE 802.3af/at
      General
      Power Supply 220V AC
      Power Consumption: ?9 W( without HDD )
      Working Environment -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ? 90% RH(non-condensing)
      Dimensions(W× D×H) 380mm ×315mm × 49.1mm(15.0" × 12.4" ×1.9" )
      Weight
      ( without HDD )
      ?2.4kg (5.29 lb)



      Uniview IPC3615SB-ADF28(40)KM-I0 Security Camera

      Camera
      Sensor 1/2.7", 5.0 megapixel, progressive scan, CMOS
      Lens 2.8mm@F1.6 / 4.0mm@F1.6
      Shutter Auto/Manual, 1 ~ 1/100000s
      Minimum Illumination Colour: 0.003Lux (F1.6, AGC ON)
      0Lux with IR on
      Day/Night IR-cut filter with auto switch (ICR)
      Digital Noise Reduction 2D/3D DNR
      S/N >56dB
      IR Range Up to 30m (98ft) IR range
      Wavelength 850nm
      IR On/Off Control Auto/Manual
      Defog Digital Defog
      WDR 120dB
      Video
      Video Compression Ultra 265, H.265, H.264, MJPEG
      H.264 code profile Baseline profile, Main Profile, High profile
      Frame Rate Main Stream:5MP (2880*1620), Max 25fps; 4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 25fps; 1080P (1920*1080), Max 30fps;
      Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
      Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
      Video Bit Rate 128 Kbps~16 Mbps
      OSD Up to 8 OSDs
      Privacy Mask Up to 4 areas
      ROI Up to 8 areas
      Motion Detection Up to 4 areas
      White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
      Digital noise reduction 2D/3D DNR
      Smart IR Support
      Flip Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
      Dewarping N/A
      HLC Supported
      BLC Supported
      Audio
      Audio Compression G.711
      Suppression Supported
      Sampling Rate 8KHZ
      Storage
      Edge Storage Micro SD, up to 256 GB
      Network Storage ANR
      Network
      Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, SNMP
      Compatible Integration ONVIF (Profile S, Profile T), API
      Client EZStation
      EZView
      EZLive
      Web Browser Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
      Plug-in free live view: Chrome 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
      Interface
      Network 1 RJ45 10M/100M Base-TX Ethernet
      Built-in Mic Supported
      Certifications
      Certifications CE: EN 60950-1
      UL: UL60950-1
      FCC: FCC Part 15
      General
      Power DC 12V±25%, PoE (IEEE 802.3af)
      Power consumption: Max 4.0W
      Dimensions (Ø x H) ?110.5 x 94.1mm (?4.4” x 3.7”)
      Net Weight 0.425kg (0.93lb)
      Material Metal
      Operating Conditions -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ?95% RH (non-condensing)
      Strorage Environment -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ?95% RH (non-condensing)
      Surge Protection 2KV
      Ingress Protection IP67
      Reset Button N/A

      Videos
      Videos

      UNV 5MP Starlight Turret + Built-in Microphone Unboxing

      Uniview Company Introduction

      Shipping
      Shipping

      FREE SHIPPING over $200! Everyday Australia Wide.

      We use the fastest Express Courier shipping available.

      A flat rate of $25 applies to orders under $200 in value.

      Orders are processed: Monday – Friday from 8am – 5pm.

      Shipping Times: Typically 1 - 3 business days or less. We can reach pretty much reach anywhere in Australia in less than 5 Business Days.

      (Public Holidays Excluded)

      Please Note: As we use courier shipping, we cannot ship to PO Boxes.

      Order Confirmation: After placing an order, you will receive an order confirmation by e-mail. This means we’ve received your order in our system and have pre-authorised your credit card for the purchase. If your item is back-ordered or otherwise unavailable, we will void the pre-authorisation charge and contact you to inform you by e-mail.  If your item(s) are available for immediate shipment (within 2 days), we will process the charges and submit the order for shipment.

      Tracking Numbers will be sent to your email once your order has shipped.

      In some cases, we may need to contact you before your order can be shipped. To ensure there is no delay, please respond to any email/phone call from our Customer Service team.

      We proudly use the following Shipping Methods.

      Customer Reviews
      5.0 Based on 2 Reviews
      5 ?
      100%
      2
      4 ?
      0%
      0
      3 ?
      0%
      0
      2 ?
      0%
      0
      1 ?
      0%
      0
      Write a Review

      Thank you for submitting a review!

      Your input is very much appreciated. Share it with your friends so they can enjoy it too!

      Filter Reviews:
      RB
      20/10/2020
      Raymond B.
      Australia Australia
      Uniview NVR

      Very easy to install, with comprehensive software interface. Should have purchased years ago.

      BA
      19/10/2020
      Brook A.
      Australia Australia
      Fantastic!!

      Superb system, easy to set up and a great price! Affordable quality! Got a sign in from the website, plugged in and the image was available through the app. Haven’t fine tuned the camera parameters such as areas for movement etc...but not really necessary at this stage.

      Free Express Shipping

      When you spend $200+

      Tax Invoice

      Automatically sent with every order

      No Hassle Returns

      We offer a 14-Day Money Back Guarantee. Terms apply

      5 Star Customer Service

      And 5 Star Reviews! We value your business, thank you!
