| Min. Illumination |
Colour:0.0005lux (F1.2, AGC ON)
0 lux with IR |
| WDR |
120dB |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| S/N |
>55dB |
| IR Range |
Up to 40m (131 ft) IR range |
| Wavelength |
850nm |
| IR On/Off Control |
Auto/Manual |
| Defog |
Digital Defog |
| Video |
| Video Compression |
Ultra 265, H.265, H.264, MJPEG |
| Frame Rate |
Main Stream: 4MP(2688*1520),Max 30fps; 4MP(2560*1440),Max 30fps; 2MP(1920*1080),Max 60fps
Sub Stream: 2MP (1920*1080), Max 60fps;
Third Stream: D1 (720*576), Max 60fps
Fourth Stream: D1 (720*576), Max 60fps
Fifth Stream: D1 (720*576), Max 60fps |
| Video Bit Rate |
128 Kbps~16 Mbps |
| ROI |
Supported |
| Video stream |
Five streams |
| OSD |
Up to 8 OSDs |
| Privacy Mask |
Up to 8 areas (8 blacks / 8 mosaics) |
| Image |
| White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital noise reduction |
2D/3D DNR |
| Smart IR |
Support |
| Flip |
Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise |
| HLC |
Support |
| BLC |
Support |
| Smart |
| General Function |
Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Audio |
| Audio Compression |
G.711U,G.711A |
| Two way audio |
Supported |
| Sampling Rate |
8KHZ |
| Storage |
| Edge Storage |
Micro SD, up to 256 GB |
| Network Storage |
ANR,NAS(NFS) |
| Network |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP |
| Compatible Integration |
ONVIF, API |
| Client |
EZStation
Ezview
EZLive |
| Web Browser |
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
| Interface |
| Audio I/O |
Audio cable |
| 1 Input: impedance 35k?; amplitude 2V [p-p] |
| 1 output: impedance 600?; amplitude 2V [p-p] |
| Alarm I/O |
1/1 |
| Network |
1 x RJ45 10M/100M Base-TX Ethernet |
| Certifications |
| Certifications |
CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15 |
| General |
Power
|
AC24V±25%, DC12V(±25%), PoE(IEEE 802.3af) |
| Power consumption: Max 10W |
| Support overcurrent protection , Input short circuit protection |
| Dimensions (Ø x H) |
?148 x 111.3mm(?5.8" x 4.4") |
| Net Weight |
0.96kg(2.12lb) |
| Material |
Metal |
| Working Environment |
-30?~60?(-22°F ~ 140°F), Humidity: ?95% RH (non-condensing) |
| Storage Environment |
-40?~70?(-40°F ~ 158°F), Humidity: ?95% RH (non-condensing) |
| Surge protection |
6KV |
| Vandal Resistant |
IK10 |
| Ingress Protection |
IP67 |
