Description
The Uniview NVR301-08X-P8 is an 8 Channel Network Video Recorder that supports high resolution cameras up to 8 megapixels/4K and features 8 POE ports providing long-distance power over ethernet up to 300 metres. PoE supports easy plug-and-play set up and can support third party cameras thanks to it's ONVIF conformance.
The NVR301-08X-P8 network video recorder allows you to search and playback recorded footage easily thanks to its fast and accurate file retrieval. It supports Ultra265 and H.265 video compression. Supported smart detections include face detection, cross-line detection, intrusion detection and people counting. The EZView smartphone app, for Uniview cameras and recorders, gives you peace of mind by allowing you to access your live feed, whether at work, on holidays or while shopping.
FEATURES
-
8 Channel Compact 4K (8MP) NVR with 8 independent POE network interfaces
- Supports 1 SATA HDD Capacity up to 10TB
- Access your Live video feed on your smart device with EZView app. Supports android and ios.
- Third-party IP cameras supported with ONVIF conformance
- HDMI and VGA simultaneous output
- Accurate retrieval, instant playback
- Supports Motion Detection, Line Crossing & Intrusion Detection, Face Detection, People Counting, Audio Detection, Loiter Detection
- ANR technology to enhance the storage reliability when the network is disconnected
- Video Compression Ultra265, H.265, MJPEG
- WARRANTY: 3 years back-to-base manufacturer warranty
More Info
Uniview 8 Channel 1 HDD NVR - NVR301-08X-P8
• Support Ultra 265/H.265/H.264 video formats
• 8-channel input
• Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
• Support 1-ch HDMI, 1-ch VGA,HDMI at up 4K(3840x2160) resolution
• HDMI and VGA simultaneous output
• Up to 8MP resolution recording
• 1 SATA HDD up to 10 TB
• Support cloud upgrade
Tech Specs
UNIVIEW NVR301-08X-P8 | 8 CHANNEL 8MP (4K) NVR
| Model |
NVR301-08X-P8 |
| Video/Audio Input |
| IP Video Input |
8-ch |
| Two-way Audio Input |
1-ch, RCA |
| Network |
| Incoming Bandwidth |
80Mbps |
| Outgoing Bandwidth |
64Mbps |
| Remote Users |
128 |
| Protocols |
P2P, UPnP, NTP, DHCP, PPPoE |
| Video/Audio Output |
| HDMI/VGA Output |
HDMI:
3840x2160/30Hz,1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
VGA:
1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| Recording Resolution |
4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output |
1-ch, RCA |
| Synchronous Playback |
8-ch |
| Corridor Mode Screen |
3/4/5/7/9 |
| Decoding |
| Decoding format |
Ultra 265/H.265/H.264 |
| Liveview/Playback |
4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability |
2 x 4k@30, 3 x 5MP@30, 4 x 4MP@30, 5 x 3MP@30,8 x 1080p@30 |
| Hard Disk |
| SATA |
1 SATA interface |
| Capacity |
up to 10TB for each disk |
| External Interface |
| Network Interface |
1 RJ45 10M/100M self-adaptive Ethernet Interface |
| USB Interface |
Rear panel: 1 x USB2.0,1 x USB3.0 |
| PoE |
| Interface |
8 independent 100 Mbps PoE network interfaces |
| Max Power |
Max 30W for single port
Max 108W in total (13.5W for each) |
| Supported Standard |
IEEE 802.3at, IEEE 802.3af |
| General |
| Power Supply |
52V DC
Power Consumption: ?8 W (without HDD) |
| Working Environment |
-10°C ~ + 55°C (+14°F ~ +131°F), Humidity ? 90% RH (non-condensing) |
| Dimensions (W×D×H) |
260mm × 240mm × 47mm (10.2"×9.4"×1.9 ") |
| Weight (without HDD) |
1kg (2.20 lb) |
