| Camera |
| Sensor |
1/2.8", 2.0 megapixel, progressive scan, CMOS |
| Lens |
4.7 ~ 47mm@F1.6 (W) ~ 3.0 (T); AF automatic focusing and motorized zoom lens |
| Iris |
DC-Iris |
| DORI Distance |
Lens (mm): 4.7
Detect (m): 72.9
Observe (m): 29.2
Recognize (m): 14.6
Identify (m): 7.3
Lens (mm): 47
Detect (m): 729.3
Observe (m): 291.7
Recognize (m): 145.9
Identify (m): 72.9 |
| Angle of View (H) |
53.8° ~ 6.6° |
| Angle of View (V) |
29.3° ~ 3.7° |
| Angle of View (O) |
66.2° ~ 7.8° |
| Adjustment angle |
Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotate: 0° ~ 360° |
| Shutter |
Auto/Manual, 1 ~ 1/100000s |
| Minimum Illumination |
Colour: 0.001Lux (F1.6, AGC ON)
0Lux with IR |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Digital noise reduction |
2D/3D DNR |
| S/N |
>52dB |
| IR Range |
up to 100m (328ft) IR range |
| Defog |
Digital Defog |
| WDR |
120dB |
| Video |
| Video Compression |
Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile |
Baseline profile, Main Profile, High Profile |
| Frame Rate |
Main Stream: 1080P (1920*1080), Max 60fps;
Sub Stream: 1080P (1920*1080), Max 60fps;
Third Stream: D1 (720*576), Max 60fps |
| 9:16 Corridor Mode |
Supported |
| HLC |
Supported |
| BLC |
Supported |
| OSD |
Up to 8 OSDs |
| Privacy Mask |
Up to 8 areas |
| ROI |
Up to 8 areas |
| Motion Detection |
Up to 4 areas |
| Smart |
| Behavior Detection |
Intrusion, cross line, motion detection |
| Intrusion |
Enter and loiter in a pre-defined virtual region |
| cross line |
Cross a pre-defined virtual line |
| motion detection |
Moving within a pre-defined virtual region |
| Recognition |
Face detection, Audio detection, lpr |
| Intelligent Identification |
Defocus, Scene Change, Object Left, Object Moving |
| Statistical Analysis |
People counting |
| General Function |
Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Audio |
| Audio Compression |
G.711 |
| Suppression |
Supported |
| Sampling Rate |
8KHZ |
| Storage |
| Edge Storage |
Micro SD, Up to 256GB |
| Network Storage |
ANR |
| Network |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS |
| Compatible Integration |
ONVIF (Profile S, Profile G), API |
| Interface |
| Interface |
Audio cable
1 Input: impedance 35k?; amplitude 2V [p-p]
1 Output: impedance 600?; amplitude 2V [p-p] |
| Alarm I/O |
2/1 |
| Serial Port |
1 RS485 |
| Network |
1 RJ45 10M/100M Base-TX Ethernet |
| Video Output |
1 BNC, impedance 75?; amplitude 1V [p-p] |
| General |
| Power |
AC 24V±25%, DC 12V±25%, PoE (IEEE 802.3at)
Power consumption: 14W |
| Dimensions (L × W × H) |
305.5 × 104.1 × 97.3mm (12.0” × 4.1” × 3.8”) |
| Weight |
1.65kg (3.6lb) |
| Working Environment |
-40°C ~ 60°C (-40°F ~ 140°F), Humidity: ?95% RH (non-condensing) |
| Ingress Protection |
IP67 |
| Reset Button |
Supported |
