| Camera |
| Sensor |
1/2.8" progressive scan, 5.0 megapixel, CMOS |
| Lens |
2.7~13.5mm?AF automatic focusing and motorized zoom lens\ |
| DORI Distance |
Lens: 2.7mm
Detect(m): 40.5
Observe(m): 16.2
Recognize(m): 8.1
Identify(m): 4.1
Lens: 13.5mm
Detect(m): 202.5
Observe(m): 81.0
Recognize(m): 40.5
Identify(m): 20.3 |
| Angle of View (H) |
105.3°~ 25.4° |
| Angle of View (V) |
69.5° ~18.4° |
| Angle of View (O) |
136.9°~30.0° |
| Adjustment angle |
Pan: 0°~350°
Tilt: 0°~90°
Rotate: 0°~350° |
| Shutter |
Auto/Manual, shutter time: 1 s ~ 1/100000 s |
| Minimum Illumination |
Colour: 0.005 lux (F1.2,AGC ON)
0 lux with IR |
| Iris |
F1.2 |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Digital noise reduction |
2D/3D DNR |
| S/N |
>55 dB |
| IR Range |
UP to 30m (98ft) |
| Defog |
Digital Defog |
| WDR |
120dB |
| Video |
| Video Compression |
Ultra 265,H.265, H.264, MJPEG |
| H.264 code profile |
Baseline profile, Main Profile, High Profile |
| Frame Rate |
Main Stream:5M (2592*1944):Max. 30 fps;
Sub Stream: 1080P (1920×1080):Max. 30 fps;
Third Stream: D1 (720×576): Max. 30 fps |
| HLC |
Supported |
| BLC |
Supported |
| EIS |
Supported |
| OSD |
Up to 8 OSDs |
| Privacy Mask |
Up to 8 areas |
| ROI |
Up to 8 areas |
| Motion Detection |
Up to 4 areas |
| Smart |
| Behavior Detection |
Intrusion, cross line, motion detection, Auto tracking |
| Intrusion |
Enter and loiter in a pre-defined virtual region |
| Cross line |
Cross a pre-defined virtual line |
| Motion detection |
Moving within a pre-defined virtual region |
| Auto tracking |
Tracking the specified target |
| Recognition |
Face detection?Audio detection |
| Intelligent Identification |
Defocus, Scene Change, Object Left, Object Moving |
| Statistical Analysis |
People counting |
| General Function |
Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP
Authentication, User Authentication |
| Heat map |
Supported |
| Audio |
| Audio Compression |
G.711 |
| Suppression |
Suppression |
| Sampling Rate |
8 KHZ |
| Storage |
| Edge Storage |
Micro SD, up to 256 GB |
| Network Storage |
ANR |
| Network |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP , PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP , 802.1x ,
SNMP, SSL |
| Compatible Integration |
ONVIF(Profile S, Profile G), API |
| Pan & Tilt |
| Pan Range |
350° |
| Pan Speed |
0.1°/s ~ 60°/s
Preset speed: 60°/s |
| Tilt Range |
0° ~ 90° (auto reverse) |
| Tilt Speed |
0.1° ~ 50°/s
Preset speed: 50°/s |
| Number of Presets |
256 |
| Patrol |
Preset patrol, route patrol, recorded patrol |
| Home Position |
Supported |
| Interface |
| Alarm I/O |
1/1 |
| Serial Port |
1 RS485 |
| Network |
1 RJ45 10M/100M Base-TX Ethernet |
| Built-in Mic |
Supported |
| Built-in Speaker |
Supported |
| WIFI |
Supported |
| General |
| Power |
DC 12V±25%, PoE (IEEE802.3 af)
Power consumption: Max 12W |
| Dimensions (Ø x H) |
?129mm×143mm(?5.07” x5.63”) |
| Weight |
3kg(6.6lb) |
| Working Environment |
–10°C ~ +50°C (14°F ~ 122°F), Humidity:10%~90% RH(non-condensing) |
| Reset Button |
Supported |
