| General |
|
| Main Processor |
Quad-core embedded processor |
| Operating System |
Embedded Linux |
| Video Input |
16 channels |
| Two-way Talk |
1 channel input, 2 channel output, RCA |
| Interoperability |
ONVIF 2.4, SDK, CGI conformant |
| Display |
|
| Video Output |
2 x HDMI, 2 x VGA |
| Display Resolution |
Configurable from 3840 x 2160 to 1024 x 768 |
| Display Split |
1/4/8/9/16 |
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
|
| Recording Resolution |
Configurable from 12.0MP (4000 x 3000) to CIF (352 x 288) |
| Incoming Bandwidth |
320Mbps |
| Decoding Capacity |
4 channels: 8.0MP (30fps) / 16 channels: 1080p (30fps) |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Bit Rate |
16kbps ~ 20Mbps per channel |
| Record Modes |
Manual / Schedule (Regular [Continuous], Motion Detection, Alarm) / Stop |
| Record Interval |
1~120 min (default: 60 min) / Pre-record: 1~30s / Post-record: 10~300s |
| Features |
|
| Alarm Input / Output |
16 channels input / 6 channels relay output (N.O/N.C) |
| Trigger Events |
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Snapshot, Buzzer, Screentips |
| Video Detection |
Motion Detection, Motion Zones: 396 (22 x 18), Video Loss & Tampering |
| Playback Sync |
1/4/9/16 |
| Search Modes |
Time/Date, Alarm, Motion Detection, Exact Search (to the second), Smart Search |
| Backup Modes |
USB Device / Network / eSATA Device |
| Network |
|
| Ethernet |
1 x RJ-45 port (10/100/1000Mbps) |
| Power over Ethernet |
16 ports (IEEE802.3at/af) / ePoE & EoC support (Ports 1-8) |
| Network Functions |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search, Easy4IP |
| Optical Interface |
N/A |
| Max. User Access |
128 users |
| Remote View |
iOS (iPhone, iPad) / Android devices |
| Storage |
|
| Internal HDD |
4 x SATA ports up to 10TB, max. 40TB HDD capacity |
| HDD Modes |
Single (no RAID compatibility) |
| USB Interface |
3 ports: Rear USB3.0 / Front USB2.0 |
| Auxiliary Inputs |
1 x RS232 / 1 x RS485 / 1 x eSATA |
| Environment |
|
| Power Supply |
100 ~ 240VAC, 50 ~ 60Hz |
| Power Consumption |
< 17.5W (without HDD) / PoE: 25.5W per port, 150W total |
| PoE |
Yes, w/ ePoE |
| Operating Environment |
-10 ~ 55°C / 10 ~ 90%RH / 86 ~ 106kpa |
| Rackmountable |
Yes (included) |
| Rackmount Units |
1.5RU |
| Dimensions |
440 x 411 x 76mm |
| Weight |
4.65kg (without HDD) |
| Warranty (Years) |
4 |
