This product has been superseded by the VIP Vision Security Camera: 4MP Turret, Professional Series, 2.7-13.5mm.Experience new standard in fixed lens IP surveillance from VIP Vision. Stream twice the resolution of full HD at up to 25fps using the latest H.265 video compression technology for the best in bandwidth/storage efficiency. This full-featured professional dome performs even in challenging lighting conditions, offers audio and microSD recording, all in an full metal IP67 weather-rated housing.
- Stream up to 4MP (2688 x 1520) at 25fps
- Utilises the H.265 high efficiency video coding standard
- 2.8mm fixed lens with wide 104° viewing angle
- Day/night (auto ICR) with 50m maximum infrared range
- True wide dynamic range WDR (120db) with back/highlight compensation
- Built-in microphone and microSD slot for edge recording
- 3D digital noise reduction 3DDNR and auto white balance AWB
- Supports Power over Ethernet PoE (802.3af)
- Supports triple stream and smart functions like Tripwire, Intrusion, Object Abandoned/Missing, Face Detection, Motion Detection, Region of Interest, Privacy Masking, Smart Infrared
- Weatherproof IP67 rated full metal housing for external use
- ONVIF, PSIA and CGI compliance
- ePoE allows for up to 800m transmission at 10Mbps (ePoE NVRs only)
- WARRANTY: 4 years back-to-base manufacturer warranty
|Image Sensor||1/3’’ 4.0MP Progressive Scan CMOS|
|Max. Resolution||4.0 Megapixel|
|Effective Pixels||2688 (H) x 1520 (V)|
|RAM / ROM||512MB / 32MB|
|Ultra Low Light Colour||No|
|Min Illumination||0.06 Lux/F2.0 (Color), 0 Lux/F2.0 (IR on)|
|S/N Ratio||> 50dB|
|Infrared System||1 x Infrared LED, 50m range, Auto/manual on/off control|
|Lens / Iris||2.8mm F2.0 Fixed Lens|
|Field of View||Horizontal: 104°, Vertical: 57°|
|DORI Distance (Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.)|
|Resolution||4.0MP (2688 x 1520) to CIF(352 x 288)|
|Frame Rate (Main)||4.0MP (1 ~ 25fps)|
|Frame Rate (Sub)||D1 (1 ~ 25fps)|
|Frame Rate (Third)||720p (1 ~ 25fps)|
|Video Compression||H.265 / H.264|
|Bit Rate||H.265: 14 ~ 9984Kbps / H.264: 24 ~ 10240Kbps|
|Bit Rate Control||Constant bit rate (CBR) / Variable bit rate (VBR)|
|Day/Night||Auto (ICR) / Color / B&W|
|Lighting Compensation||BLC / HLC / WDR (120dB)|
|White Balance||Auto / Natural / Street Lamp / Outdoor / Manual|
|Gain Control||Auto / Manual|
|Noise Reduction||3D DNR|
|Picture Control||Mirror / Flip (0°, 90°, 180°, 270°)|
|Intelligent Functions||Tripwire, Intrusion, Object Abandoned/Missing, Face Detection, Motion Detection (4 zones), Region of Interest (4 zones), Privacy Masking (4 zones), Smart Infrared|
|Protocol||HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP; NTP; Bonjour; 802.1x; Multicast; ICMP; IGMP; SNMP|
|Streaming Method||Unicast / Multicast|
|Max. User Access||10 Users / 20 Users|
|Audio Interface||Built-in Microphone / Compression: G.711a, G.711Mu, AAC, G.726|
|Edge Storage||MicroSD Card (up to 128GB) / NAS / Local PC|
|Interoperability||ONVIF Profile S&G / API|
|Power Supply||12VDC / PoE (802.3af) (Class 0)|
|Power Consumption||< 5.2W|
|Operating Conditions||-30° ~ +60° C / Less than 95% RH|
|Pan/Tilt/Rotation||Pan: 0° ~ 360 ° ; Tilt: 0° ~ 78° ; Rotation: 0° ~ 360°|
|Dimensions||Ø106mm x 94mm|
