Camera |
|
Image Sensor |
1/2.8” 2.0MP Progressive Scan CMOS |
Max. Resolution |
2.0 Megapixel |
Effective Pixels |
|
RAM / ROM |
512MB / 128MB |
Min Illumination |
|
S/N Ratio |
> 56dB |
Infrared System |
N/A |
Lens |
|
Lens Type |
Fixed |
Lens / Iris |
2.8mm Fixed Focal Lens with Fixed Iris |
Field of View |
Horizontal: 107°, Vertical: 55° |
Focus |
Auto Focus / 0.8m Min. Focus Distance |
DORI |
|
Detect (25px/m) |
47m |
Observe (63px/m) |
19m |
Recognise (125px/m) |
9m |
Identify (250px/m) |
5m |
Video |
|
Resolution |
1080p (1920 x 1080) to CIF (352 x 288) |
Frame Rate (Main) |
|
Frame Rate (Sub) |
|
Frame Rate (Third) |
|
Video Compression |
H.265+ / H.265 / H.264+ / H.264 / H.264H / MJPEG |
Bit Rate |
H.265: 12 ~ 8192Kbps / H.264: 32 ~ 8192Kbps |
Bit Rate Control |
Constant bit rate (CBR) / Variable bit rate (VBR) |
Day/Night |
|
Lighting Compensation |
|
White Balance |
Auto / Natural / Street Lamp / Outdoor / Manual |
Gain Control |
Auto / Manual |
Noise Reduction |
3D DNR |
Picture Control |
Mirror / Flip (0°, 90°, 180°, 270°) |
IVS |
|
Intelligent Functions |
Motion Detection (4 zones), Region of Interest (4 zones), Privacy Masking (4 zones), Smart Illumination, Defog, Object Abandoned / Missing |
Perimeter Protection |
Tripwire, Intrusion, fast moving, loitering detection, people gathering, parking detection (Add recognition of humans & vehicles) |
Face Detection |
N/A |
Face Attributes |
N/A |
People Counting |
Supports people counting (Displays enter no., leave no. and pass no.), area people counting ( Count no. people or stay time / 4 rules configuration), Queue Management (Counts no. people or stay time / 4 rules configuration) |
Heat Map |
Yes |
Event Trigger |
Motion Detection, Video Tampering, Scene Changing, Network Disconnection, IP Address Conflict, Illegal Access, Storage Anomaly |
Intelligent Search |
Via NVR Smart Search, Search tripwire/intrusion events by people or vehicle |
Network |
|
Ethernet |
|
Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP |
Streaming Method |
|
Max. User Access |
20 Users |
Interface |
|
Video Interface |
N/A |
Audio Interface |
Built-in Mic / Built-in Speaker / Audio Compression - G.711a; G.711Mu; G726; AAC; G723 |
Alarm Interface |
1 channel in: 5mA 5VDC / 1 channel out: 300mA 12VDC |
RS485 |
N/A |
Edge Storage |
MicroSD Card (up to 256GB) / NAS / FTP / SFTP |
Interoperability |
ONVIF (Profile S, Profile G) / P2P / CGI / Milestone / Genetec |
Environmental |
|
Power Supply |
|
Power Consumption |
<7.3W |
Operating Conditions |
|
Ingress Protection |
IP67 |
Vandal Resistance |
N/A |
Series |
|
Camera Type |
Turret |
Housing |
Metal |
Pan/Tilt/Rotation |
Pan: 0° ~ 360°, Tilt: 0° ~ 78°, Rotation: 0° ~ 360° |
ePoE |
No |
Dimensions |
|
Net Weight |
0.75kg |
Other |
LED Illumination |
