| Camera |
|
| Image Sensor |
1/2.8’’ 4.0MP Starvis™ CMOS |
| Max. Resolution |
4.0 Megapixel |
| Effective Pixels |
|
| RAM / ROM |
1GB / 4GB |
| Min Illumination |
0.005 Lux/F1.35 (Colour), 0.0005 Lux/ F1.35 (B/W)/, 0 Lux (IR Light On) |
| S/N Ratio |
N/A |
| Infrared System |
4 x Infrared LED, 150m range, Zoom Prio/Auto/Manual/Smart IR On/Off control |
| Lens |
|
| Lens Type |
|
| Lens / Iris |
4.9mm ~ 156mm F1.35~ F4.4 Motorised Lens |
| Field of View |
61.6° ~ 2.1° (H), 35.1°~ 1.3° (V), 68.2 ~2.5 ° (D) (32x Optical Zoom) |
| Focus |
Auto/Semi-Auto/Manual / 0.1m ~ 1.5m Min. Focus Distance |
| DORI |
|
| Detect (25px/m) |
3120m |
| Observe (63px/m) |
1232m |
| Recognise (125px/m) |
624m |
| Identify (250px/m) |
312m |
| PTZ |
|
| Pan / Tilt Range |
Pan: 0° ~ 360° (endless) / Tilt: -15° ~ 90° / Auto Flip 180° |
| PTZ Speed |
Preset: Pan: 400°/s; Tilt: 300°/s Manual: Pan: 300°/s; Tilt: 200°/s |
| Modes / Presets |
Up to 300 presets / 5 Pattern, 8 Tour, 5 scanning, Auto Pan, Auto Scan |
| Start-up Action |
Auto-restore to previous PTZ/lens status |
| Video |
|
| Resolution |
4.0MP (2560 x 1440) to CIF (352 x 288) |
| Frame Rate (Main) |
|
| Frame Rate (Sub) |
D1(1 ~ 25fps) |
| Frame Rate (Third) |
720p (1 ~ 25fps) |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 / H.264B / H.264H /MJPEG |
| Bit Rate |
H.265/H.264: 3 kbps–20480 kbps |
| Bit Rate Control |
Constant bit rate (CBR) / Variable bit rate (VBR) |
| Day/Night |
|
| Lighting Compensation |
|
| White Balance |
Auto / Indoor / Outdoor / Tracking / Manual / Sodium lamp / Natural light / Street lamp |
| Gain Control |
Auto / Manual |
| Noise Reduction |
2D / 3D DNR |
| Picture Control |
Flip 0°/180° |
|
|
| Face Recognition |
N/A |
| Face Capture |
N/A |
| Perimeter Protection |
Tripwire & Intrusion (Add recognition of humans & vehicles) |
| Auto Tracking |
Support |
| Metadata |
Supports human, motor vehicles and non motor vehicle search. Supports face image capture and footage search by face image & facial attributes |
| People Counting |
N/A |
| Heat Map |
N/A |
| Intelligent Video Surveillance (IVS) |
| IVS Functions |
Abandoned/Missing Object, Motion Detection, Region of Interest, Electronic Image Stabilisation, Privacy Masking (24 zones), Defog |
| Event Triggers |
Motion Detection, Video Tampering , Audio Detection, Scene Changing, Network Disconnection, IP Address Conflict, Illegal Access, Storage Anomaly |
| Region of Interest |
Support |
| Optical Defog |
Support |
| Digital Zoom |
16x |
| Privacy Masking |
Up to 24 areas, and up to 8 areas in the same view |
| Image Stabilisation |
Support |
| Network |
|
| Ethernet |
|
| Protocol |
IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3 (MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP |
| Streaming Method |
|
| Max. User Access |
20 Users |
| Interface |
|
| Video Interface |
N/A |
| Audio Interface |
1 Input / 1 Output / Compression: G.711A; G.711Mu; G.726; AAC; G.722.1; G.723; G.729; PCM; MPEG2-Layer2 |
| Alarm Interface |
|
| RS485 |
N/A |
| Edge Storage |
FTP; Micro SD card (256G); P2P |
| Interoperability |
|
| Environmental |
|
| Power Supply |
24VAC/3A (±25%) / PoE+ (802.3at) |
| Power Consumption |
|
| Operating Conditions |
-40° ~ +70° C / Less than 95% RH |
| Ingress Protection |
IP67 |
| Vandal Resistance |
IK10 |
| Series |
|
| Camera Type |
PTZ Dome |
| Housing |
Metal |
| Pan/Tilt/Rotation |
Pan: 0° ~ 360°, Tilt: -15° ~ 90° |
| ePoE |
N/A |
| Dimensions |
|
| Net Weight |
4.7kg |
| Other |
|
| Intelligent Search |
Via NVR Smart Search, Search tripwire/intrusion events by people or vehicle |
| SMD+ |
Filter motion detection alarms, recognises humans and vehicles from other moving objects |
| Surge Protection |
TVS 6000V Lightning Protection / Surge Protection |
| Warranty (Years) |
4 |
