Networking Specifications |
| Gigabit Ethernet RJ45 PoE Port |
8 |
| Gigabit SFP Port |
2 |
| Ethernet Performance |
| Switching Bandwidth |
20 Gbps |
| MAC Address |
4 K |
| Buffer Memory |
128 KB |
| Forwarding Capacity |
14.88 Mbps |
| Jumbo Frame |
9,216 Bytes |
| Transmission Method |
Store and Forward |
| Auto-MDI/MDI-X, Auto-Negotiation |
Supported |
| Standards |
| IEEE 802.3 10-BASE-T (Ethernet) |
Supported |
| IEEE 802.3u 100-BASE-TX (Fast Ethernet) |
Supported |
| IEEE 802.3ab 1000-BASE-T (Gigabit Ethernet) |
Supported |
| IEEE 802.3af/at |
Supported |
| IEEE 802.3z 1000-BASE-X (Gigabit Ethernet) |
Supported |
| IEEE 802.3x Flow Control (Full-Duplex Flow Control) |
Supported |
| IEEE 802.3af Power over Ethernet |
Supported |
| IEEE 802.3at Power over Ethernet Plus |
Supported |
| Power Specifications |
| Power Input Voltage |
PW1: 48 ~ 56VDC
PW2: 48 ~ 56VDC
Redundant Power Backup |
| Max. PoE Output Power /Per PoE Port |
54VDC, Max. 30W |
| Total PoE Power Budget |
120W |
| IEEE 802.3af/at |
Supported |
| Power Pin Assignment |
1/2(+), 3/6(-) |
| PoE PD Auto Detection |
Supported |
| Surge Protection/Per PoE Port |
12KV |
| General |
| Operating Temperature |
-40°C ~ 75°C (-40°F ~ 167°F) |
| Storage Temperature |
-40°C ~ 85°C (-40°F ~ 185°F) |
| Operating Humidity |
5%-95% non-condesing |
| Dimensions |
172 (L) x 132 (W) x 39 (H) mm |
| Weight |
0.8 kg |
| Certifications |
| EMS |
EN61000-4-2 ESD, EN61000-4-3 RS, EN61000-4-4 EFT, EN61000-4-5 Surge, EN61000-4-6 CS, EN61000-4-8 PFMF |
| EMI |
FCC Part 15 Class AFCC Part 15 Class A |
| Safety |
CE, LVD, VCCI |
| Vibration |
IEC 60068-2-6 |
| Shock |
IEC 60068-2-27 |
| Freefall |
IEC 60068-2-32 |
