Playback Display |
4 Channels Multi Layout Display |
Playback Control |
Regular (Play, Pause, Stop), Rewind, Next / Previous Frame, Speed Control, Calendar, Event, Timeline, Timeline Scale, Thumbnail (Storyboard) |
Video Search |
By calendar, date/time, and alarm |
Thumbnail Explorer (Storyboard) |
Listing the thumbnail of recorded video (Max. 2 CH) |
Video Clip Export |
Supported |
Network |
Ethernet |
10/100/1000Mbps Ethernet (RJ-45) x2 |
Network Throughput Input/Output Total |
224Mbps |
PoE |
802.3at/af compliant PoE ports x 8 (total Max. 120W) * DO NOT suggest connecting any non-PD device with this NVR PoE port in order to avoid potential risk. |
PoE Management |
Supported |
External Interface |
USB |
Front x1 (USB 3.0) Back x2 (USB 2.0) |
Alarm In |
4 |
Alarm Out |
1 |
Audio In/ Out |
3.5 Phone Jack Audio Output x1 3.5 Phone Jack Audio Input x1 (reserved) |
System |
Camera Integration |
ONVIF Profile S |
Event |
Motion Detection, Smart VCA Event, Cyber Attack, PIR Detection, Tampering Detection, Camera DI/DO, Camera Disconnected, Disk Failure, Disk Full, NVR DI/DO, PoE error, Video loss |
Event Action |
Record, Email (Text), Email (Snapshot), FTP, Buzzer, ePTZ Control (Go to Preset), NVR DO, Camera DO, APP Notification by cloud service |
User Management |
User level: administrator, regular user |
Date & Time |
Time Zone, Manual Automatic Sync NTP, Daylight saving Time |
Deep Search |
Object Search |
People, Vehicle |
Scene Search |
Line crossing, Intrusion, Loitering |
Attribute Search |
People: Gender, Age, Clothing Color, Accessories Vehicles: Type, Color |
Advanced Features |
VCA Counting Solution |
Supported |
VCA Event Search |
Supported |
Smart Search II |
Supported |
Trend Micro IoT Security |
Supported |
Cybersecurity Management |
Supported |
Remote Client |
Software AP |
Shepherd, VSS (VAST Security Station) |
Mobile/Tablet App |
iViewer , VIVOCloud, VORTEX(Android & iOS) |
Web Browser |
Chrome |
General |
Power Input |
100-240V AC, 50/60Hz |
Power Consumption |
Max. 270 W |
Dimensions |
365 (W) x 315 (D) x 44 (H) mm |
Weight |
2.78 kg |
Operating Temperature |
-10°C ~ 55°C (14°F ~ 131°F) |
Humidity |
0 ~ 95% |
Safety Certifications |
CE, FCC, VCCI, C-Tick, UL, CB, BSMI, BIS |
