| Audio Capability |
One-way Audio (Full duplex) |
Audio Compression |
G.711, G.726, MPEG-2 AAC-LC |
Audio Interface |
Built-in microphone |
| Effective Range |
5 meters |
Network |
Users |
Live viewing for up to 10 clients |
Security |
Access list, Account block , Audit log, Configurable password strength protection, CSRF protection, Digest authentication, HTTPS , IEEE 802.1x, Secure boot, Session timeout, Signed firmware, Trend Micro IoT Security (Brute force attack event, Cyberattack event, Quarantine event), User access log, User account management |
| Protocols |
802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2, UDP, UPnP |
Interface |
10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard. |
AI Analytics |
Compute Capability |
SoC with built-in hardware deep learning accelerator |
Vision Object Analytics |
Object Detection: People, Vehicle (4-wheeled, 2-wheeled); Attribute Extraction: People (gender, clothing color, bag, hat), Vehicle (bike, bus, car, motorcycle, truck, color); Re-Search Extraction; Path Extraction |
Application |
Deep Learning VCA (Smart Motion Detection, Smart VCA)
Smart Motion Detection (Five-window video motion detection, People detection, Vehicle detection, Time filter), Smart VCA (Intrusion detection, Loitering detection, Line crossing detection, Unattended object detection, Missing object detection, Face detection, Crowd detection |
Application available with license |
Running detection, Parking Violation Detection, Restricted Zone Detection
Support for more analytic applications and free trial, please visit https://vivotek.com/video-analytics |
Solution Integration |
Applications |
Stratocast, Trend Micro IoT Security (3-year free trial) |
Alarm and Event |
Event Trigger |
Audio detection, camera tampering detection, cybersecurity events (brute force attack event, cyberattack event, quarantine event), manual trigger, motion detection, periodical trigger, recording notification, SD card life expectancy, shock detection, system boot |
Event Action |
Event notification via camera link, email, HTTP, FTP/SFTP, NAS server, SD card
File upload via email, HTTP, FTP/SFTP, NAS server, SD card |
General |
Connectors |
RJ-45 cable connector for 10/100Mpbs Network/PoE connection |
LED Indicator |
System power and status indicator |
| Power Input |
IEEE 802.3af PoE Class 0 |
| Power Consumption |
Max: 8.55W (IR on)
Max: 6.15W (IR off) |
| Dimensions |
Ø 129 x 94 mm |
| Weight |
605 g |
| Certifications |
EMC: CE (EN 55032/EN 55035 Class A, EN 50121-4), FCC (FCC Part 15 Subpart B Class A), UKCA (BS EN 55032/BS EN 55035 Class A),RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A), IC (ICES-003 Issue 7); Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471), LVD, (EN 62368-1), UKCA (BS EN IEC 62368-1); Environment: IK10 (IEC 62262), IP66/67 (IEC 60529), NEMA (NEMA 250 Type 4X), IEC 60068-2-11; IA: BIS (IS 13252), BSMI (EMC: CNS 13438, Safety: CNS 14336-1) |
| Operating Temperature |
Starting Temperature:
-30°C ~ 60°C (-22°F ~ 140°F)
Working Temperature:
-40°C ~ 60°C (-40°F ~ 140°F) (IR off)
-40°C ~ 50°C (-40°F ~ 122°F) (IR on) |
| Humidity |
98% RH (non-condensing) |
System Requirements |
| Operating System |
Microsoft Windows 10/8/7
Mac 10.12 (Chrome only) |
| Web Browser |
Chrome 58.0 or above
Internet Explorer 10/11 |
| Other Players |
VLC: 1.1.11 or above |
Included Accessories |
| Packing Contents |
Quick installation guide, product labels, alignment sticker, L-shaped wrenssory pack, sunshield, adapting plate, conduit bracket, I/O cable |
| Optional Accessories |
Please refer to Accessory Selection Guide |
