Camera Features |
Image sensor |
1/2.8" Progressive CMOS |
Resolution |
SD: 1280 x 960
HD: 2560 x 1920
|
Lens Types |
Motorized, Vari-focal, Remote Focus |
Focal Length |
f = 2.7 ~ 13.5 mm |
Aperture |
F1.4 ~ F2.8 |
Iris |
P-iris |
Field of View |
95° ~ 30° (Horizontal)
70° ~ 23° (Vertical)
128° ~ 38° (Diagonal)
|
Camera Movement |
Pan: ±180 Tilt: 90° Rotate:±180° |
Shutter Speed |
1/5 sec. to 1/32,000 sec. |
Day/Night |
Yes |
IR Cut Filter |
Yes |
IR Range |
50 meters |
WDR Technology |
WDR Pro |
Minimum Illumination |
0.075 lux @ F1.4 (Color)
<0.01 lux @ F1.4 (B/W)
0 lux with IR illumination on
|
Onboard Storage |
MicroSD/SDHC/SDXC card slot
(Built-in 256GB industrial SDCard)
|
Standard Video Settings |
Frame Rate |
15FPS |
Video Streaming Settings |
HD Video 2560 x 1920@15fps 1.2Mbps upload
SD Video 1280 x 960@15fps 300Kbps upload
|
Standard Audio Settings |
Audio |
Two-way Audio |
Interface |
External microphone Input
External line output
|
Effective Range |
- |
Power and Network |
Power input |
AC 24V, DC 12V, IEEE 802.3at PoE Class 4 (Power Redundancy) |
Power Consumption |
PoE: MAX 25W / 20W (IR on/off)
DC12V: MAX 29.5W / 24W (IR on/off)
AC24V: MAX: 28W/22.5W (IR on/off)
|
Connectivity |
"RJ-45 cable connector for 10/100 Mbps PoE network connection
Audio line input
Audio line output
DC 12V power input/AC 24V power input
Digital input*2
Digital output*2
|
RTSP |
WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, IPv6, NTP, QoS (CoS/DSCP), RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP |
Users |
Up to 6 clients
*Live viewing for 6 clients
*live viewing up to 4 clients and playback 2 clients)
|
Security |
Secure boot
Signed firmware
HTTPS/TLS encryption
Video encryption
|
Interface |
10 Base-T/100 Base-TX Ethernet
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard. |
General |
Operating Temperature |
Starting Temperature:
-10°C ~ 60°C (14°F ~ 140°F)
Working Temperature:
-30°C~ 60°C (-22°F ~ 140°F) (IR Off)
-30°C ~ 50°C(-22°F ~ 122°F) (IR On)
|
Humidity |
90% RH (non-condensing) |
Certifications |
EMC: CE (EN55032 Class A,EN55035), FCC (FCC Part 15 Subpart B Class A), ICES-003 issue 7,RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A); Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 62471,IEC/EN 60950-22); Environment; IK10 (IEC
62262), IP66 (IEC 60529)
|
Warranty |
120-month |
Included Accessories |
Quick installation guide, alignment sticker, screw pack, cable gland |
Mechanical |
Weight |
1421g |
Dimensions |
Ø118 x 294.6 mm |
Body |
Metal |
AI Analytics |
Audio detection |
Yes |
Tampering detection |
Yes |
People Analytics |
Intrusion detection, Line crossing detection, Loitering detection, Attribute Search, Scene Search, Re-Search, Profile Search |
Vehicle Analytics |
Intrusion detection, Line crossing detection, Loitering detection, Attribute Search, Scene Search, Re-Search, Profile Search |
Object Analytics |
Unattended object detection, Missing object detection |
