| Model |
VSIPP-8DD-ID3 |
| Camera Type |
Fixed 180° AI Deterrence Turret |
| Image Sensor |
1/2.7” 8.0MP Progressive Scan CMOS |
| Effective Pixels |
4096 (H) x 1860 (V) |
| RAM / ROM |
1GB / 128MB |
| Min Illumination |
0.005 Lux/F1.4 (Colour), 0.0005 Lux/F1.4 (B/W), 0 Lux (IR) |
| Infrared System |
1 x Infrared LED (25m range, Auto/Manual) |
| LED Illumination |
1 x Spotlight (Warm White), 1 x Red & Blue Alarm Light |
| Lens / Iris |
2.8mm F1.4 Fixed Lens |
| Field of View |
Horizontal: 180°, Vertical: 86° |
| Focus |
Auto Focus / 0.8m Min. Focus Distance |
| Video Resolution |
8.0MP (4096 x 1860) to 960 x 432 |
| Frame Rate |
Main: 8.0MP (1~20fps), Sub: 1200x530 (1~20fps), Third: 1920x860 (1~20fps) |
| Video Compression |
H.265+, H.265, H.264+, H.264, H.264B, MJPEG |
| Bit Rate |
H.265: 6~16384Kbps / H.264: 6~16384Kbps |
| Lighting Compensation |
BLC / HLC / WDR (120dB) |
| Smart Scene Adaptive |
Yes |
| White Balance |
Auto / Natural / Street Lamp / Outdoor / Manual / Regional Custom |
| Noise Reduction |
3D DNR |
| AI Functions |
People & Vehicle Detection, Perimeter Protection, Tripwire, Intrusion |
| Event Triggers |
Motion Detection, Video Tampering, Scene Changing, Network Disconnection, Storage Anomaly |
| Ethernet |
RJ-45 (10/100Base-T) |
| Protocol Support |
IPv4/6, HTTP, TCP, UDP, RTSP, FTP, DDNS, QoS, UPnP, NTP, SNMP, P2P |
| Audio Interface |
Built-in Mic & Speaker / PCM, G.711a/u, G.726, G.723 |
| Alarm Interface |
1 In (5mA 3–5VDC) / 1 Out (300mA 12VDC) |
| Edge Storage |
MicroSD (up to 256GB) / NAS / FTP / SFTP |
| Interoperability |
ONVIF (Profile S, G, T) / CGI |
| Power Supply |
12VDC / PoE (802.3af) |
| Power Consumption |
<8.7W (12VDC) / <10.85W (PoE) |
| Operating Conditions |
-40°C ~ +60°C / ≤95% RH |
| Ingress Protection |
IP67 |
| Housing |
Metal |
| Dimensions |
Ø 122mm × 135mm |
| Net Weight |
0.99kg |
