| Display |
2.4 inch TFT LCD Color Screen |
| Operation System |
Linux |
| Card Capacity |
50,000 (Optional: 100,000) |
| Logs Capacity |
200,000 (Optional: 1000,000) |
| User Password |
6 Digits |
| RFID |
Standard Module: ID Optional Multi-Tech Card Module: |
| Module 1 Support ID&IC& DESFire EV1/EV2; |
| Module 2 Support ID&IC& DESFire EV1/EV2&Feliac&Legic&HID Prox; |
| Module 3 Support ID&IC& DESFire EV1/EV2&Feliac&Legic&HID Prox&HID iclass; |
| Communication |
TCP / IP, Wiegand, RS485, OSDP (Ver2.1.7), RS232 (only for printer), Wi-FI (Optional) |
| Wired Network |
10 / 100 Mbps, Auto MDI/MDI-X |
| Access Control Interface |
3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell |
| Auxiliary Interface |
1 AUX input |
| Indication Light |
Breathing light: White, Status light: Red / Green |
| Hardware |
1GHz Dual Core CPU, DDR2 64M, Flash 256M |
| Data Protection |
AES-256 Encryption |
| Keypad Hidden |
Touch Keypad |
| Wiegand Signal |
Wiegand In / Out |
| Standard Functions |
ID card, Web sever, Automatic Status Switch, Self-Service Query,
DST, 14 Digit User ID, Scheduled Bell, Anti-passback,
HTTPS, Protocol convert (AC push to TA push)
|
| Optional Functions |
Wi-Fi, Multi-tech Card Module, Printer |
| Power Supply |
DC 12V 3A |
| Operating Temperature |
-10°C to 55°C (14°F to 131°F) |
| Storage Temperature |
-20°C to 60°C ( -4°F to 140°F) |
| Operating Humidity |
10% to 90% RH |
| Dimensions |
(L*W*D) 143*85*19.8mm |
| Protocol |
A & C Push (default) / T&A Push |
| Supported Software |
ZKBioAccess IVS |
