Camera Features |
Image sensor |
1/2.7" Progressive CMOS |
Resolution |
HD 4864 x 1632 (8MP)
SD 2432x 816
|
Lens Types |
Fixed-focal |
Focal Length |
f = 2.8 mm |
Aperture |
F1.2 |
Iris |
Fixed iris |
Field of View |
180° (Horizontal)
50° (Vertical)
180° (Diagonal)
|
Camera Movement |
Tilt: 20° |
Shutter Speed |
1/30 sec. to 1/32,000 sec. |
Day/Night |
Yes |
IR Cut Filter |
Yes |
IR Range |
20 meters |
WDR Technology |
WDR Pro |
Minimum Illumination |
0.018 lux @ F1.2 (Color), 30IRE
<0.01 lux @ F1.2 (B/W)
0 lux with IR illumination on
|
Onboard Storage |
MicroSD/SDHC/SDXC card slot
(Built-in 512GB industrial SDCard)
|
Standard Video Settings |
Frame Rate |
15FPS |
Video Streaming Settings |
HD 4864 x 1632 (8MP)@15fps 3Mbps upload
SD 2432x 816@15fps 400Kbps upload
|
Standard Audio Settings |
Audio |
One-way Audio |
Interface |
Built-in microphone |
Effective Range |
5 meters |
Power and Network |
Power input |
IEEE 802.3at PoE Class 4 |
Power Consumption |
Max: 20 W / 13.5W (IR on/ IR off) |
Connectivity |
RJ-45 cable connector for 10/100 Mbps PoE network connection |
RTSP |
WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, IPv6, NTP, QoS (CoS/DSCP), RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP |
Users |
Up to 6 clients
*Live viewing for 6 clients
*live viewing up to 4 clients and playback 2 clients)
|
Security |
Secure boot
Signed firmware
HTTPS/TLS encryption
Video encryption
|
Interface |
10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard
|
General |
Operating Temperature |
Starting Temperature:
-30°C ~ 55°C (-22°F ~ 131°F)
Working Temperature:
-40°C ~ 50°C (-40°F ~ 122°F) (IR on)
|
Humidity |
90% RH (non-condensing) |
Certifications |
EMC: CE (EN 55032/EN 55035 Class A), UKCA (BS EN 55032/BS EN 55035 Class A), FCC (FCC Part 15 Subpart B Class A), RCM (AS/
NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A), IC (ICES-003 Issue 7, Class A);
Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471), LVD (IEC/EN 62368-1), UKCA (BS EN 62368-1);
Environment: IK10 (IEC 62262), IP66(IEC 60529)
|
Warranty |
120-month |
Included Accessories |
Quick installation guide, alignment sticker, desiccant bag, screw driver, screws pack, sunshield |
Mechanical |
Weight |
1.2 kg |
Dimensions |
165 x 112 x 97 mm (w/o sunshield)
165 x 100 x 119 mm (w/ sunshield)
|
Body |
Metal |
AI Analytics |
Audio detection |
Yes |
Tampering detection |
Yes |
People Analytics |
Intrusion detection, Line crossing detection, Loitering detection, Attribute Search, Scene Search, Re-Search, Profile Search |
Vehicle Analytics |
Intrusion detection, Line crossing detection, Loitering detection, Attribute Search, Scene Search, Re-Search, LPR Search |
Object Analytics |
Unattended object detection, Missing object detection |
